一种新颖的燃烧室出口温度场调试方法

胡好生; 赵坚行; 钟建平; 蒋荣伟; 尹美芝

一种新颖的燃烧室出口温度场调试方法

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
中国航空动力机械研究所, 株洲 412002

计量
- 文章访问数: 1489
- HTML浏览量: 0
- PDF量: 425
- 被引次数: 0
出版历程
- 收稿日期: 2006-09-19
- 修回日期: 2006-10-30
- 刊出日期: 2007-08-28

A new adjustment method of combustor outlet temperature field

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
China Aviation Power-plant Research Institute, Zhuzhou 412002, China

摘要

摘要: 以某小型回流燃烧室为基础验证平台, 试验研究改变燃油喷嘴插入火焰筒涡流器组件深度对燃烧室出口温度场的影响, 并对试验结果进行了比较和分析.结果表明:对同一燃烧室, 燃油喷嘴与火焰筒涡流器组件之间有一个最佳的轴向位置, 此时的燃烧室的出口温度分布系数最小;在相同的燃烧室工作状态, 采用不同喷雾锥角的燃油喷嘴, 这个最佳位置不同.该研究为燃烧室出口温度场的调试及燃烧室的研制提供了一条有效的技术途径.
- 航空、航天推进系统 /
- 回流燃烧室 /
- 燃油喷嘴轴向位置 /
- 出口温度分布系数 /
- 试验研究 /
- 温度场调试
Abstract: Based on a testing platform of a small-sized reverse combustor, the effect of different axial locations of fuel nozzle in the swirler on combustor outlet temperature field is studied by experiment.And, the experimental results are also compared and analyzed.Experimental data show that, for the same combustor, there is an optimized axial location between the fuel nozzle and the swirler.In such case, the pattern factor of outlet temperature is minimum;Under the operating state of the same combustor, the optimized axial location of the fuel nozzle changes with the fuel nozzle spray angle.This study thus provides an effective technical approach to adjust the outlet temperature field and develop the combustor.
- aerospace propulsion system /
- reverse combustor /
- axial location of fuel nozzle /
- pattern factor of outlet temperature /
- experimental investigation /
- temperature field adjustment

HTML

参考文献(4)

[1]	Lefebvre A H.Gas turbine combusiion[M].Philadelphia:Taylor-Francis,1999.
[2]	Chen Y,Scarborough D,Liang S,et al.Manipulating pattern factor using synthetic jet actuators[R].AIAA 2000-1023,2000.
[3]	John C D,Kevin J B,Joseph R S,et al.Active combustion control for aircraft gas turbine engines[R].AIAA 2000-3500,2000.
[4]	郑严,沈倍毅.弹用涡喷发动机燃烧室出口温度场试验与分析[J].推进技术,2001,22(3):187-190.ZHENG Yan,SHEN Beiyi.Tests and analysis of exit temperature distribution of the combustor for missile turbojet[J].Journal of Propulsion Technology,2001,22 (3):187-190.
