数值分析二级涡流器环形燃烧室的燃烧性能
Numerical analysis of combustion performance in an annular combustor with two-stage swirler
-
摘要: 采用多维经验分析法在任意曲线坐标系下对包括二级突扩扩压器、双级轴向涡流器及火焰筒在内的单头部环形燃烧室的燃烧性能进行计算.并对RNGk-ε紊流模型加以改进, 使其更适用于数值模拟非交错贴体坐标系下的三维两相化学反应流.采用EBU-Arrhenius紊流燃烧模型、六通量热辐射模型以及颗粒群轨道模型对油雾燃烧进行模拟.同时, 数值分析了不同涡流器几何尺寸对燃烧室整体流场和燃烧性能的影响, 数值计算结果与实验数据相当一致, 表明计算方法合理, 计算程序可靠, 可用来估算环形燃烧室的燃烧性能.Abstract: In an arbitrary curvilinear coordinate system, a multidimensional empirical analysis methodology was developed to calculate the combustion performance of an annular combustor, which consists of the dump diffuser, two-stage flame tube and cooling passages.The RNG k-ε turbulent model was also modified, for enabling correct calculations of three-dimensional and two-phase turbulent reactive flows under a non-staggered grid system.Spray combustion was simulated through EBU-Arrhenius turbulent combustion model, six-flux radiation model and particle trajectory model.And numerical analysis was conducted for the effects of the geometry of swirlers on entire combustor flow fields and combustion performances.Predictions and measurements were in satisfactory agreement, and it was shown that numerical procedures are fairly reasonable and reliable for estimating the combustion performances of annular combustors.
-
[1] Mansour A,Benjamiin M.A new hybrid air blast nozzle for advanced gas turbine combustor[R].ASME,2000 GT-0117,2000. [2] 党新宪.单头部双旋流器环形燃烧室性能实验研究与和数值模拟[D].南京:南京航空航天大学,2005. [3] Chong M C,Jiang Z.A comprehensive liguid fuel injection model for CFD simulatipons of gas turbine combustors[R].AIAA,2005-349,2005. [4] 雷雨冰,赵坚行.三级涡流器环形燃烧室化学反应流场的数值研究[J].推进技术,2005,26(3):215-218.LEI Yubing,ZHAO Jianxing.Numerical study of reacting flow field in the annual combustor with the tripe swirler[J].Journal of Propulsion Technology,2005,26 (3):215-218. [5] Mongia H C.Perspective of combustion modeling for gas turbine combustors[R].AIAA,2004-0156,2004. [6] 赵坚行.燃烧的数值模拟[M].北京:科学出版社,2002. [7] Yakhot V,Orzag S A.Renormalization group analysis of turbulence:basictheory[J].J Scient Comput,1986,1:3-5. [8] Choudhury D.Introduction to the renormalization group method and turbulence modeling[M].Fluent Inc.TM-107,1993. [9] 雷雨冰.数值模拟环形燃烧室整体流场[D].南京:南京航空航天大学,2000. [10] Yakhot V,Orzag S A,Thangam S.Development of turbulence models for shear flows by double expansion technique[J].Phys Fluids A,1992,4(7):1510-1520. [11] 范维澄,万跃鹏.流动及燃烧的模型与计算[M].合肥:中国科学技术大学出版社,1992.215. [12] Mognia H C.Combining Lefebvre's correlations with Combuster CFD[R].AIAA 2004-3544,2004. -
