带隔热屏加力燃烧室热态流场计算
Turbulent combustion flow field calculation for afterburner with heat shied
-
摘要: 在任意曲线坐标系下对带有横向波纹隔热屏、外冷却通道和尾喷口的涡喷加力燃烧室的三维热态流场进行数值模拟.利用椭圆型微分方程和区域法生成三维贴体网格, k-ε模型预估紊流特性, EBU-Arre-henius紊流燃烧模型估算化学反应速率, 六通量模型预估辐射通量以考虑其对壁面和气流温度的影响.在非交错网格系统下应用混合差分格式离散控制方程, SIMPLE算法求解离散方程, 数值分析两种进口气流参数分布对加力室热态流场和壁温分布的影响.所得计算值与试验数据基本相符, 表明计算方法合理.
-
关键词:
- 航空、航天推进系统 /
- 数值计算, 加力燃烧室, 隔热屏, 贴体网格
Abstract: In an arbitrary curvilinear coordinate system, numerical simulation was performed for 3D turbulent combustion flow field of the afterburner with the cross-rippled heat shield, outer cold passage and jet nozzle.The body-fitted grids were generated using a system of elliptical partial differential equations.The k-ε model was employed to describe the turbulent characteristics.EBU-Arrehenius turbulent combustion model was used to determine the chemical reaction rate, while a six-flux model was applied to predict heat radiation and its influence on the wall and gas temperature.The discretion of governing equations in a non-staggered grid system was obtained by hybrid scheme and was solved with SIMPLE algorithm.The influences of two different inlet gas parameter distributions on afterburner flow characteristics and wall temperature profiles were analyzed numerically.Calculations were in good agreement with the experimental data and show that numerical procedures are fairly reasonable.-
Key words:
- aerospace propulsion system /
- numerical simulation
-
[1] 赵坚行.燃烧的数值模拟[M].北京:科学出版社,2002. [2] 侯晓春,季鹤鸣,赵坚行.高性能航空燃气轮机燃烧技术[M].北京:国防工业出版社,2002. [3] Khalil E E.Modelling of furances and combustors[M].Tunbridge Well,Kent:Abacus Press,1982. [4] Zhao J X.Three-dimensional gas turbine combustor performance modeling[J].Transactions of Nanjing University of Aeronautics and Astronautics,2002,19 (1):65-70. [5] 刘洪.加力燃烧室隔热屏优化设计[D].南京:南京航空航天大学,1997. [6] 赵坚行,刘全忠.加力室隔热屏流场计算[J].工程热物理学报,1995,16(4):491-494.ZHAO Jianxing,LIU Quanzhong.The prediction of turbulent reacting flow in a afterburner with heat shield[J].Journal of Engineering Thermophysics,1995,16(4):491-494. [7] 雷雨冰.数值模拟环形燃烧室整体流场[D].南京:南京航空航天大学,2000.12.
