减阻表面换热特性的实验

基金项目: 航空科学基金资助项目(04C51028)

Experimental investigation on heat transfer characteristics of drug-reduction surface

National Key Laboratory on Aero-engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要: 采用实验方法对带"V"型沟槽表面通道在不同雷诺数下的流动与换热特性进行了研究.研究结果表明:宽与深均为0.5 mm的沟槽板通道在实验范围内具有明显的减阻效果, 减阻效果随着雷诺数的增大而减小;相比平板通道流动, 低雷诺数范围下(10000
- 航空、航天推进系统 /
- 减阻表面 /
- 雷诺相似 /
- 流动换热
Abstract: The heat transfer characteristics of ribbed surfaces with rectangular channel were experimentally studied under different Reynolds numbers.The experimental results indicate that the small longitudinal ribbed surface of h=s=0.5 mm has great drag-reduction characteristics within the test range, and its drag-reduction declines with the increase of Reynolds number.As compared with heat flow in flat plate channel, the heat transfer characteristics of ribbed surface decreases in the case of 10 0001).Moreover, the heat transfer enhancement ratio increases with Reynolds number under test conditions.
- aerospace propulsion system /
- drag-reduction surface /
- Reynolds analogy /
- heat transfer

[1]	Eckert E R G.传热传质分析[M].航青,译.北京:科学出版社,1981.Eckert E R G.The analysis of heat and mass transfer[M].Beijing:Science Press,1981.
[2]	葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京:科学出版社,1985.GE Shaoyan,LIU Dengying,XU Jingzhong,et al.Film cooling[M].Beijing:Science Press,1985.
[3]	Walsh M J,Weinstein L M.NASA Langley research center[J].AIAA Journal,1988.17 (3) 770-771.
[4]	Choi K S.Near-wall structure of a turbulent boundary layer with riblets[J].Journal of Fluid Mech,1989,208:417-458.
[5]	Walsh M J,Weinstein L M.Drag and heat transfer characteristics of small longitudinal ribbed surfaces[J].AIAA J,1979,17(7):770.
[6]	Choi K S,Hamid S.Heat transfer study of riblets[M].[S.l.]:[S.n.],Recent Development in Turbulent Management,1991:25-41.
[7]	王晋军.沟槽面湍流减阻研究综述[J].北京航空航天大学学报,1998,24(1):31-34.WANG Jinjun.The research summary of turbulence dragreduce in grooved surface[J].Journal of Beijing University of Aeronautics and Astronautics,1998,24 (1):31-34.
[8]	闻洁,赵桂林.表面具有流向微槽叶片的传热性能分析[J].汽轮机技术,1998,40(6):358-359.WEN Jie,ZHAO Guiling.The analysis of heat transfer performance of the blade surface with micro-groove[J].Gas Turbine Technology,1998,40(6):358-359.
