微小“T”型蒸发管蒸发率实验

朱菁; 郭新华; 林宇震; 徐国强

微小“T”型蒸发管蒸发率实验

北京航空航天大学能源与动力工程学院航空发动机气动热力重点实验室, 北京 100083

计量
- 文章访问数: 1592
- HTML浏览量: 104
- PDF量: 455
- 被引次数: 0
出版历程
- 收稿日期: 2006-07-31
- 修回日期: 2006-10-27
- 刊出日期: 2007-08-28

Experimental research on vaporization rate of micro"T"-vaporizer

National Key Laboratory on Aero-engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 研究了微小尺寸"T"型蒸发管燃油蒸发率在不同工况下的变化规律.实验中蒸发管入口空气常压.实验研究了气油比、蒸发管入口空气温度、蒸发管壁温度和蒸发管入口空气流速对蒸发率的影响.试验结果表明, 气油比、蒸发管入口空气温度和蒸发管壁温是影响蒸发率的主要因素.蒸发管入口空气流速对蒸发率的影响较小.该蒸发管在管壁和进口空气同时加温, 并且气油比大于4.5的条件下, 蒸发率接近100%, 蒸发效果好.
- 航空、航天推进系统 /
- 微小型发动机 /
- 微小T型蒸发管 /
- 蒸发率
Abstract: The variations of vaporization rate of Micro "T"-Vaporizer under various working conditions were studied.The experiments were conducted at vaporizer inlet under normal atmospheric pressure.The main influential factors to vaporization rate were tested, which include the air/fuel ratio, inlet air temperature, vaporizer wall temperature and the velocity of the airflow into the vaporizer.The experimental results show that, the air/fuel ratio, inlet air temperature and vaporizer wall temperature are major influential factor to vaporization rate.But, the velocity of the inlet airflow is less influential.The vaporization rate of the micro Tvaporizer is nearly 100%, when inlet air and vaporizer tube wall are heated simultaneously and the air/fuel ratio is more than 4.5.
- aerospace propulsion system /
- micro engine /
- micro T-vaporizer /
- vaporization rate

HTML

参考文献(8)

[1]	SOTHERAN A.The Rolls-Royce annular vaporizer combustor[R].ASME Paper 83-GT-49.1983.
[2]	胡正义.蒸发管内雾化和蒸发过程的研究[J].燃气涡轮试验与研究,1989,2(4):45-54.HU Zhengyi.A study of atomization and evaporation in a fuel vaporizer[J].Gas Turbine Experiment and Research,1989,2(4):45-54.
[3]	江义军.蒸发式燃油喷射装置蒸发性能研究[J].航空动力学报,1990,5(1):32-34.JIANG Yijun.Research on evaporation performance for fuel spray vaporizer[J].Journal of Aerospace Power,1990,5(1):32-34.
[4]	张洪才,孙跃忠,李铁菊,等.蒸发管喷嘴燃油雾化特性试验研究[J].燃气涡轮试验与研究,1988,1(1):47-50.ZHANG Hongcai,SUN Yuezhong,LI Tieju,et al.An experimental study on fuel spray atomizing characteristics of evaporation pipe atomizer[J].Gas Turbine Experiment and Research,1988,1(1):47-50.
[5]	程树海.缩短燃烧室火焰长度的试验研究[R].中国航空科技文献,HJB880634,1989.
[6]	Schreckling K.Gas turbine engines for model aircraft[M].[S.l.]:Traplet Distribution USA Ltd,1996.
[7]	Gerendás M,Pfister R.Development of a very small aeroengine[R].ASME Paper 2000-GT-0536,2000.
[8]	Lefebvre A H.Gas turbine combustion[M].Philadelphia:Taylor & Francis,1999.
