基于旋转坐标系转轴振动信号的滚动轴承故障诊断方法

基金项目: 航空科学基金资助项目(98J52082)

A diagnostic approach to rolling element bearing based on vibration signal of shaft in a rotating reference frame

Instituteof Monitoring and Control for Rotating Machinery and Wind Turbines Northwestern Polytechnical University, Xi'an 710072, China

摘要: 实验验证了基于旋转坐标系转轴振动信号的滚动轴承局部故障诊断方法.建立起滚动轴承故障实验台, 采用压电晶体加速度传感器测取转轴的振动.通过滚动轴承内环、外环、滚动体和保持架四种典型故障的实验分析结果, 证明了该方法的可行性, 并发现转轴振动信号的传递路径相对简单, 对轴承内环、滚动体和保持架早期微小故障的发现与诊断可能是有利的.
- 滚动轴承 /
- 局部故障 /
- 旋转坐标系 /
- 加速度传感器 /
- 频谱 /
- 包络解调谱
Abstract: In order to diagnose local defects in a rolling element bearing, an approach was developed based on vibration signal of shaft in a rotating reference frame.A test rig for rolling element bearing was established, and piezoelectric accelerometers were used to measure the vibration signals of shaft.The feasibility of this approach was demonstrated by the experimental results from four typical defects involving inner race, outer race, rolling element and cage.It was found that the transmission path of vibration signals of shaft is relatively simple, contributing to early detection and diagnosis of minor defects for inner race, outer race, rolling element and cage.
- a rolling element bearing /
- local defect /
- rotating reference frame /
- piezoelectric accelerometer /
- spectrum /
- envelope spectrum

[1]	樊可清.基于回转振动信号的机械诊断技术研究[D].西安:西安交通大学,1998.
[2]	梅宏斌.滚动轴承振动监测与诊断理论·方法·系统[M].北京:机械工业出版社,1995.
[3]	McFadden P D,Smith J D.Vibration monitoring of rolling element bearings by the high-frequency resonance technique-a review[J].Tribol Int 1984,17:3-10.
[4]	汪玉,刘东岳,廖明夫.一种诊断转子故障的方法:中国,200410028999.7[P].2004-04-05.
[5]	雷继尧,罗东升.压电角加速度式扭振遥测系统的研究[J].重庆大学学报,1985:36-43.LEI Jirao,LUO Dongsheng.Research and design of system of piezoelectric angular acceleration used in remote measuring torsional vibration[J].Journal of Chongqing University(Natural Science Edition),1985,9 ; 36-43.
[6]	孟涛.齿轮与滚动轴承故障的振动分析与诊断[D].西安:西北工业大学,2003.
[7]	McFadden P D.Model for the vibration produced by a single point defect in a rolling element bearing[J].Journal of Sound and Vibration,1984,96:69-82.
