涡扇发动机高空起动模型研究
Research on the startup model of turbofan engine at high altitude
-
摘要: 基于慢车以上的部件级模型, 通过外推部件特性, 建立了双转子涡扇发动机部件级高空起动模型, 可执行高空风车起动或起动机起动仿真.模型考虑了起动过程中油气比对燃烧效率的影响, 燃烧室、高低压涡轮的热惯性及起动过程中总压恢复系数的变化, 采用容积动力学方法避免了迭代运算, 仿真结果表明该模型具有实时性, 仿真转速误差小于5%, 能够满足发动机高空起动性能仿真的需求.Abstract: Based on the above-idle component-level model, a two-spool turbofan engine startup model was developed according to extrapolated component characteristics.The model can simulate the startup of windmilling and starter at high altitude.This model has taken into account the influence of fuel-air ratio on combustion efficiency, heat transfer model was built up to estimate the influence of heat transfer on combustor, thermal inertia of combustor and high-/low-pressure turbine as well as the change of total pressure recovery coefficients of different components during startup.The method of volume dynamic was used in order to avoid iterative calculations.The simulation results show that the real-time model has a simulated speed error less than 5%, making it possible to meet the demand of high-altitude startup performance simulation for aeroengine.
-
[1] Agrawal R K,Yunis M.A generalized mathematical model to estimate gas turbine starting characteristics[R].ASME 81-GT-202,1981. [2] Kim J H,Song T W,Kim T S,et al.Dynamic simulation of full startup procedure of heavy-duty gas turbines[J].Journal of Engineering for Gas Turbines and Power,2002,124:510-516. [3] 黄向华,郑绪生.基于逐级叠加法的航空发动机起动模型研究[J].航空学报,2005,26(5):540-544.HUANG Xianghua,ZHENG Xusheng.Research on startup model of aircraft engine based on stage-stacking method[J].ACTA Aeronautica ET Astronautica Sinica,2005,26(5):540-544. [4] 雷积红,陈策,李军,等.基于BP神经网络的涡扇发动机部件特性研究[J].燃气涡轮试验与研究,2003,16(4):15-17.LEI Jihong,CHEN Ce,LI Jun,et al.A Study of Turbofan Component Characteristic Based on Back-propagation Network[J].Gas Turbine Experiment and Research,2003,16(4):15-17. [5] Chappell M A,McLaughlin P W.Approach to modeling continuous turbine engine operation from startup to shutdown[R].AIAA 91-2373,1991. [6] 冷步里,朱鸿义.模拟单转子发动机起动性能的计算模型[J].燃气涡轮试验与研究,1999,12(1):25-29.LENG Buli,ZHU Hongyi.Single spool engine starting characteristic simulation model[J].Gas Turbine Experiment and Research,1999,12(1):25-29. [7] 周文祥,黄金泉,窦建平.涡扇发动机部件级起动模型研究[J].航空动力学报,2006,21(2):248-253.ZHOU Wenxiang,HUANG Jinquan,DOU Jianping.Development of component-level startup model for a turbofan engine[J].Journal of Aerospace Power,2006,21 (2):248-253. [8] Sexton W R.A new method to control turbofan engine starting by varying compressor surge valve bleed[D].Blacksburg,Virginia State,USA:Thesis for Master's Degree of Virginia Polytechnic Institute and State University,2001:14-66. [9] Pilidis P.The effect of heat transfer on gas turbine transients[R].ASME 86-GT-275,1986.
