密度差和速度比对单排孔气膜冷却效率的影响

李丽; 彭晓峰; 王补宣

密度差和速度比对单排孔气膜冷却效率的影响

清华大学热能工程系相变及界面传递实验室, 北京 100084

计量
- 文章访问数: 1713
- HTML浏览量: 222
- PDF量: 424
- 被引次数: 0
出版历程
- 收稿日期: 2006-08-24
- 修回日期: 2006-12-10
- 刊出日期: 2007-09-28

Influence of density ratio and velocity ratio upon the cooling effect of flat panel film

Laboratory of Phasechange and Interfacial Transport Phenomena, Department of Thermal Engineering, Tsinghua University, Beijing 100084, China

摘要

摘要: 采用传热传质类比的方法研究主射流密度差和速度比对单排孔平板气膜冷却效率的影响.密度比为1时射流为空气, 密度比为1.5和2.0射流为异质气体, 射流与主流的夹角为35°, 孔间距为3倍的气膜孔直径.结果表明:当速度比较小时, 射流在被保护壁面上的铺展由扩散控制;当速度比较大时, 铺展由对流控制.在较低速度比条件下, 随着吹风比的增大, 横向和纵向的铺展都增加, 有效保护范围面积增加;高速度比条件下, 射流的再附点随着动量比的增大而更向下游.
- 航空、航天推进系统 /
- 气膜冷却 /
- 传热传质类比 /
- 绝热温比
Abstract: An investigation was conducted to explore the influence of density ratio and velocity ratio of mainstream/injectant upon the cooling effect of flat plane film using heat-mass transfer analogy.The injectant is air in the case of density ratio of 1.0,or heterogeneous gas in the case of density ratio of 1.5 and 2.0.The inclined angle between injectant and mainstream is 35° and the hole spacing is 3 times film hole diameter.The results indicate that,the spreading of injectant is controlled through the protected wall surface for a low velocity ratio,and controlled by convection for a high velocity ratio.With the increase of mass flux ratio,the transverse and longitudinal spreading could be expanded,thus increasing effectively the protective range;the reattachment point will move towards the downstream with the increase of momentum ratio under high velocity ratio.
- aerospace propulsion system /
- film cooling /
- heat-mass transfer analogy /
- adiabatic film effectiveness

HTML

参考文献(7)

[1]	葛绍岩,刘登瀛,徐靖中,等.气膜冷却[M].北京:科学出版社,1985.
[2]	Eckert E R G.Analogies to heat transfer processes[M].Washington:Hemisphere Publishing Corp.1986.
[3]	Goldstein R J,Eckert E R G.Effects of hole geometry and density on three-dimensional film cooling[J].Int.J.Heat Mass Transfer,1974,17:595-606.
[4]	Pedersen D R,Eckert E R G,Goldstein R J.Film cooling with large density difference between the mainstream and the secondary fluid measured by the heat-mass transfer analogy[J].J.Heat Transfer,Transaction of ASME,1977,4(99):620-627.
[5]	Ammari H D,Hay N,Lampard D.The effect of density ratio on the heat transfer coefficient from a film-cooled flat plate[J].J.Turbomachin,1990,112:444-450.
[6]	Leontiev A I.Heat and mass transfer problems for film cooling[J].J.Heat Transfer,1999,121(33):509-527.
[7]	Hale C A,Plesniak M W,Ramadhyani S.Film cooling effectiveness for short film cooling holes fed by a narrow plenum[J].J.Turbomachin,2000,122:553-557.
