航空发动机燃烧室喷油环三维流场数值模拟

Numerical simulation of 3-D flow field in an aeroengine combustor nozzle-loop

School of Power and Enery, Northwestern Polytechnical University, Xi'an 710072, China

摘要: 针对所研究喷油环的结构特点, 采用四面体非结构化网格和疏密结合的网格划分方法, 生成喷油环网格计算模型, 对喷油环三维流场进行数值模拟计算, 较为详细地分析了单个喷嘴内部流场特性以及喷油环的出口流量分布情况.计算结果为进一步研究喷油环流量分布特性提供了坚实的基础.
- 航空、航天推进系统 /
- 喷油环 /
- 喷嘴 /
- 三维流场 /
- 数值模拟
Abstract: According to the structural characteristic of the nozzle-loop,a grid calculation model of nozzle-loop was generated by using tetrahedral unstructured grid and thin & thick grid meshing method.And,numerical simulation was performed for the 3-D flow field of nozzle-loop,providing in detail the interior flow characteristic of single nozzle and the outflow flux of nozzle-loop.The results lay a firm basis for further research of nozzle-loop's flux distribution trait.
- aerospace propulsion system /
- nozzle-loop /
- nozzle /
- 3-D flow /
- numerical simulation

[1]	Kano H,Kato M,Kojima T.Contribution of optimum for nozzle configuration to spray formation[R].SAE,1990,900824:1765-1779.
[2]	Okajima M,Kato M,Tojo S.Contribution of optimun nozzle design to injection rate control[R].SAE,1991,912185:232-245.
[3]	Date K,Manable M,Kano H.Contribution of fuel flow improvement in nozzle to spray formation[R].SAE,1992,920622:1149-1159.
[4]	杨立军,张向阳,高芳,等.液体喷嘴动态特性数值模拟[J].航空动力学报,2004,19(6):866-872.YANG Lijun,ZHANG Xiangyang,GAO Fang,et al.Numerical simulation of liquid injector dynamics[J].Journal of Aerospace Power,2004,19(6):866-872.
[5]	岳明,徐行,杨茂林.离心式喷嘴内气液两相流动的数值模拟[J].工程热物理学报,2003,24(5):888-890.YUE Ming,XU Hang,YANG Maolin.Numerical study of two-phase flow in atomizer[J].Journal of Engineering Thermophysics,2003,24(5):888-890.
[6]	苏铭德,黄素逸.计算流体力学基础[M].北京:清华大学出版社,1997.
[7]	韩占忠,王敬,兰小平.FLUENT流体工程仿真计算实例与应用[M].北京:北京理工大学出版社,2005.
