跨声压气机动静干涉效应的数值研究

毛明明; 宋彦萍; 王仲奇

跨声压气机动静干涉效应的数值研究

哈尔滨工业大学能源科学与工程学院, 哈尔滨 150001

基金项目: 国家自然科学基金(No.50646021); 高等学校博士学科点专项科研基金(No.20060213007)

计量
- 文章访问数: 1695
- HTML浏览量: 172
- PDF量: 501
- 被引次数: 0
出版历程
- 收稿日期: 2007-01-25
- 修回日期: 2007-04-20
- 刊出日期: 2007-09-28

Numerical research on influence of rotor-stator interactions in transonic compressor

School of Energy Science and Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 采用数值方法对一轴流跨声压气机在设计点的非定常流场进行了模拟, 对级内动静干涉进行了深入分析, 研究了尾迹和位势作用等对动静叶表面气动负荷的影响.计算结果表明:在压气机中, 上游动叶的尾迹等对静叶通道内部流动, 叶片表面静压的波动, 以及边界层流动损失的发生、发展和输运产生明显的影响, 需要在设计中加以考虑.
- 航空、航天推进系统 /
- 非定常流动 /
- 跨声压气机 /
- 动静干涉 /
- 尾迹 /
- 位势作用
Abstract: The unsteady flow field of a single stage axial transonic compressor at a design point was simulated numerically,and an in-depth analysis of rotor-stator interaction was performed.Moreover,the influences of upstream wakes and potential effects on downstream blade loading distributions were investigated extensively.The results indicate that,under stage environment,upstream wakes have obvious influences on generation,evolution and transportation of flow losses,and also on loading distributions of downstream blade.Therefore,consideration shall be given to this effect in the design of turbomachinery.
- aerospace propulsion system /
- unsteady flow /
- transonic compressor /
- rotor-stator interaction /
- wake /
- potential effect
