跨声速多级轴流压气机非设计性能预测
Off-design performance prediction of multi-stage transonic axial compressor
-
摘要: 基于公开发表的研究成果, 发展了一种适用于跨声速轴流压气机的新型损失和落后角模型, 并进行了3-D的修正, 运用改进的流线曲率法对某两级跨声速轴流压气机进行了数值模拟, 得到了设计点和非设计点的特性曲线.通过计算结果与实验值的比较, 验证了本模型和方法在设计点和非设计点均具较高的精度, 可用于工程计算.Abstract: A new loss and deviation model suitable for multi-stage transonic axial compressor was developed according to the research findings publicly available.Along with 3-D modification,numerical simulation was performed for two-stage transonic axial compressor using an improved streamline curvature method,thus obtaining the characteristic curve of design point and off-design point.By combining the calculated results with experimental value,this model and method are suitable for engineering calculation with higher accuracy of design point and off-design point.
-
[1] Denton J D.Computational fluid dynamics for turbomachinery design[J].J.Mech.Eng.Sci,1999,213(c2). [2] Boyer K M.An improved streamline curvature approach for off-design analysis of transonic compression systems[D].Blacksburg,VA:Ph.D.Dissertation,Mechanical Engineering Dept.Virginia Polytechnic Institute and State University,April,2001. [3] Joseph E.Identification and evaluation of loss and deviation models for use in transonic compressor stage performance prediction[D].Blacksburg,VA:MS Thesis,Mechanical Engineering Dept.Virginia Polytechnic Institute and State University,September,1997. [4] Cetin M,Ucer A S,Hirsch CH,et al.Application of modified loss and deviation correlations to transonic axial compressors[R].AGARD-R-745,1987. [5] Bloch G S,Copenhavor W W,O' Brien W F.A shock loss model for supersonic compressor cascades[J].Transactions of the ASME,Journal of Turbomachinery,January,1999,121:28-35. [6] 秦鹏译.轴流压气机气动设计[M].北京:国防工业出版社1975. [7] White N M,Tourlidakis A,Elder R L.Axial compressor performance modelling with a quasi-one-dimensional approach[J].Proc Instn Mech Engrs,Part A:J Power and Energy,2002,216. [8] Creveling H F,Carmody R H.Axial-flow compressor computer program for calculating off-design performance[R].NASA-CR-72472,1968. [9] Klepper J.Technique to predict stage-by-stage,pre-stall compressor performance characteristic using a streamline curvature code with loss and deviation correlations[D].Knoxville,TN:MS Thesis,University of Tennessee,August.1998. [10] Koch C C,Smith L H Jr.Loss sources and magnitudes in axial-flow compressors[J].Transactions of the ASME,Journal of Engineering for Power,July,1976:411-424. [11] Miller G R,Lewis G W Jr,Hartmann M J.Shock losses in transonic compressor blade rows[J].Transactions of the ASME,Journal of Engineering for Power,July 1961:235-242. [12] Urasek D C,Gorrell W T,Cunnan W S.Performance of two-stage fan having low-aspect-ratio,first-stage rotor blading[R].NASA TP-1493,1979.
