叶栅二次流旋涡结构与损失分析

林奇燕; 郑群; 岳国强

叶栅二次流旋涡结构与损失分析

哈尔滨工程大学动力与能源工程学院, 哈尔滨 150001

计量
- 文章访问数: 1809
- HTML浏览量: 264
- PDF量: 609
- 被引次数: 0
出版历程
- 收稿日期: 2006-08-24
- 修回日期: 2006-12-25
- 刊出日期: 2007-09-28

Analysis of secondary flow vortex structure and losses in turbine cascades

College of Power and Energy Engineering, Harbin Engineering University, Harbin 150001, China

摘要

摘要: 采用三维粘性程序对某型动力涡轮的第一级进行了数值模拟, 模拟结果捕捉到了该涡轮级叶栅的内部流的流动细节, 展示了涡轮叶栅端壁和型面流动及叶栅通道内的三维流动结构.通过对叶栅中的二次流现象和流动损失机理的分析, 揭示了该涡轮级叶栅通道内二次流旋涡结构(马蹄涡、通道涡、壁角涡、尾迹涡、泄漏涡等)的演变过程, 以及旋涡结构对损失分布的影响.
- 航空、航天推进系统 /
- 二次流损失 /
- 涡系结构 /
- 尾迹涡 /
- 间隙流动 /
- 动力涡轮 /
- 数值模拟
Abstract: Numerical simulation about the first stage of a power turbine was performed using 3D viscous code,showing that the details in this turbine stage were captured.And,the flow characteristics of endwalls and blade surfaces for these cascades and the structures of 3D flow field were also presented.After analysis of secondary flow phenomenon and loss mechanism,the evolution process of secondary flow vortex structures in cascade passage(horseshoe vortex,passage vortex,corner vortex,trailing vortex,tip leakage vortex,etc) were revealed,and the effects of vortex structures on loss distribution were also studied.
- aerospace propulsion system /
- secondary flows losses /
- vortex structures /
- trailing vortex /
- tip clearance flow /
- power turbine /
- numerical simulation

HTML

参考文献(10)

[1]	王仲奇,冯国泰,王松涛,等.透平叶片中的二次流旋涡结构的研究[J].工程热物理学报,2002,23(5):553-556.WANG Zhongqi,FENG Guotai,WANG Songtao,et al.Study on secondary flow vortex structures in turbine blades[J].Journal of Engineering Thermophysics,2002,23(5):553-556.
[2]	周逊,韩万金,王仲奇.后加载叶型叶栅的拓扑与旋涡结构[J].热力透平,2005,34(1):1-6.ZHOU Xun,HAN Wanjin,WANG Zhongqi.Topology vortex structure of turbine cascades with aft-loaded profile[J].Thermal Turbine,2005,34(1):1-6.
[3]	Puddu P,Palomba C,Nurzia F.Time-space evolution of secondary flow structures in a two-stage low-speed turbine[R].ASME Paper,2006-GT-90787.
[4]	von Hoyningen-Huene M,Frank W,Jung A R.Three-dimensional time-resolved flow field in the first and last turbine stage of a heavy duty gas turbine,Part Ⅰ:Secondary flow field[R].ASME Paper,2000-GT-0438.
[5]	Hermanson K S,Thole K A.Effect of inlet conditions on endwall secondary flows[J].Journal of Propulsion and Power,2000,16(2):286-296.
[6]	钟兢军,王会社,贾剑波,等.压气机叶栅内二次流的数值研究[J].航空动力学报,2001,16(4):398-400.ZHONG Jingjun,WANG Huishe,JIA Jianbo,et al.Numerical simulation of secondary flow in compressor cascade[J].Journal of Aerospace Power,2001,16(4):398-400.
[7]	Hj(a)rne J,Chernoray V,Larsson J,et al.An experimental investigation of secondary flows and loss development downstream of a highly loaded low pressure turbine outlet guide vane cascade[R].ASME Paper,2006-GT-90561.
[8]	Pecnik R,Pieringer P,Sanz W.Numerical investigation of the secondary flow of a transonic turbine stage using various turbulence closures[R].ASME Paper,2005-GT-68754.
[9]	贾希诚,王正明.叶轮机械中间隙流与通道二次流相互作用的数值研究[J].航空动力学报,2002,17(4):399-403.JIA Xicheng,WANG Zhengming.Numerical study of interaction between clearance flow and passage secondary flow in turbomachinery[J].Journal of Aerospace Power,2002,17(4):399-403.
[10]	祁明旭,丰镇平.透平动叶顶部间隙流的端壁二次流结构研究[J].西安交通大学学报,2005,39(5):445-449.QI Mingxu,FENG Zhenping.Study on tip clearance flow of turbine blade-endwall secondary flow structure[J].Journal of Xi'an Jiaotong University,2005,39(5):445-449.
