气体动压轴承-转子动力系统稳定性及分岔

康伟; 张家忠; 刘雁; 任晟

气体动压轴承-转子动力系统稳定性及分岔

1.
西安交通大学能源与动力工程学院, 西安 710049
2.
西北工业大学机电工程学院, 西安 710072

计量
- 文章访问数: 1552
- HTML浏览量: 1
- PDF量: 431
- 被引次数: 0
出版历程
- 收稿日期: 2006-09-11
- 修回日期: 2006-12-30
- 刊出日期: 2007-09-28

Stability and bifurcation of symmetrical rotor in self-acting gas journal bearings

1.
School of Energy and Power Engineering, Xi'an Jiaotong University, Xi'an 710049, China
2.
School of Mechatronic Engineering, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 基于非线性动力学理论, 研究了普通圆柱型径向气体动压轴承支承的转子动力系统的运动稳定性和分岔.建立了气体动压轴承-Jeffcott转子系统的力学模型, 并采用有限元方法逼近非定常气体雷诺方程, 得到任意时刻的气膜力;数值模拟该非线性动力系统的长期行为, 得到了轴颈中心的运动轨迹;并采用轨迹图、相图、分岔图以及功率谱等, 研究了系统的非线性行为以及不平衡响应的稳定性.研究结果表明:该方法对气体轴承中存在的气膜涡动问题能够给予合理的解释.
- 航空、航天推进系统 /
- 气体动压轴承 /
- 有限元法 /
- 稳定性 /
- 非线性 /
- 分岔
Abstract: Based on the nonlinear dynamics theory,the stability and bifurcation of a symmetrical rotor supported in self-acting gas bearings were studied.A dynamic model of self-acting gas journal bearings and Jeffcott rotor system was established,meanwhile the finite element method was used to approach the time-dependent Reynolds equation,thus obtaining the gas film force.Furthermore,the longterm nonlinear dynamic behaviors of the system were simulated numerically,so the system state trajectory of journal center was acquired.Moreover,the system state trajectory,phase diagram,bifurcation diagram and power spectrum were adopted to analyze the nonlinear behaviors of system and the stability of unbalanced response.The results show that this method could give a deep understanding of whirling instability of the gas film bearings-rotor system.
- aerospace propulsion system /
- self-acting gas journal bearings /
- finite element method /
- stability /
- nonlinearities /
- bifurcation

HTML

参考文献(7)

[1]	王元勋,陈尔昌,师汉民,等.气体润滑轴承的研究与发展[J].湖北工学院学报,1994,9(3):155-159.WANG Yuanxun,CHEN Erchang,SHI Hanmin,et al.Research and development of gas-lubricated bearing[J].Journal of Hubei Polytechnic University,1994,9(3):155-159.
[2]	Ausman J S.Linearized ph stability theory for translatory half-speed whirl of long,self-acting gas-lubricated journal bearings[J].ASME,Journal of Basic Enginerring,1963,85(4):611-619.
[3]	Sternlicht B.Elastic and damping properties of cylindrical journal bearings[J].ASME Trans.,Journal of Basic Engineering,1959,81:101-108.
[4]	Heshmat H,Walowit J A,Pinkus O.Analysis of gas-lubricated foil journal bearings[J].ASME Trans.,Journal of Lubrication Technology,1983,105:647-655.
[5]	Lund J W.Calculation of stiffness and damping properties of gas bearings[J].ASME,Journal of Lubrication Technology,1968,90.Series F:793-803.
[6]	Czolczynski K,Kapitaniak T.Hopf bifurcation in rotors supported in gas barings[J].Chaos Solitons & Fractals,1997,8(4):499-515.
[7]	Wang C C,Chen C K.Bifurcation analysis of self-acting gas journal bearings[J].ASME,Journal of Tribology,2001,123(44):755-767.
