磁悬浮助推发射气动力分析及风洞试验

陈晓东; 杨文将; 刘宇; 段毅

磁悬浮助推发射气动力分析及风洞试验

北京航空航天大学宇航学院, 北京 100083

基金项目: 国家863基金

计量
- 文章访问数: 1751
- HTML浏览量: 202
- PDF量: 446
- 被引次数: 0
出版历程
- 收稿日期: 2007-03-16
- 修回日期: 2007-06-13
- 刊出日期: 2007-09-28

Aerodynamic analysis and wind tunnel testing on maglev launch assist

School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 通过分析磁悬浮助推发射装置的空气动力特征, 提出了其气动外形设计的合理原则.分析了磁悬浮橇体和支撑分离机构的气动外形方案, 并确定了优化的气动外形设计参数值.考虑地面效应模拟的同时, 在FD-06风洞中进行了缩比模型试验.结果表明, 升阻力系数随着马赫数或运载器迎角的增大而增大, 装置有上仰的趋势, 迎角为0°时, 阻力系数较小, 各系数的变化也较小.
- 航空、航天推进系统 /
- 磁悬浮 /
- 助推发射 /
- 风洞试验 /
- 空气动力
Abstract: The aerodynamic characteristics of a maglev(or magnetic levitation) launch assist vehicle were analyzed and rational design principles for its aerodynamic shape were proposed.The aerodynamic shape configuration for the maglev sled as well as for the support and separation structure was analyzed and the optimal values of design parameters were obtained.A wind tunnel testing for a scale model was made in the FD-06 wind tunnel,in which simulation ground effect was considered.The results show that the lift and drag coefficient increases along with the increase of Mach number or the attack angle of the space vehicles.The launch assist vehicle has a tendency to face upward.When the attack angle is zero,the drag coefficient is relatively small and the variation of each coefficient is relatively small too.
- aerospace propulsion system /
- magnetic levitation /
- launch assist /
- wind tunnel testing /
- aerodynamics

HTML

参考文献(8)

[1]	杨文将,刘宇,杨博.航天发射用磁悬浮助推发射系统概念研究[J].北京航空航天大学学报,2005,31(1):105-110.YANG Wenjiang,LIU Yu,YANG Bo.Conceptual study of magnetic launch assist system for space launch[J].Journal of Beijing University of Aeronautics and Astronautics,2005,31(1):105-110.
[2]	Schetz J A.高速列车空气动力学[J].力学进展,2003,33(3):404-423.Schetz.J A.Aerodynamics of high-speed trains[J].Advances in Mechanics,2003,33(3):404-423.
[3]	张东俊,王延奎,邓学蓥.高升阻比乘波体外形设计及气动特性计算研究[J].北京航空航天大学学报,2004,30(5):429-433.ZHANG Dongjun,WANG Yankui,DENG Xueying.Design and computational study of waverider configuration with high performance[J].Journal of Beijing University of Aeronautics and Astronautics,2004,30(5):429-433.
[4]	刘建新.高速机车减阻及外型流线化的结构实现[J].交通运输工程学报,2001,1(1):102-104.LIU Jianxin.The structure design about the driver's cab of high speed locomotive[J].Journal of Traffic and Transportation Engineering,2001,1(1):102-104.
[5]	傅立敏.汽车空气动力学[M].北京:机械工业出版社,1998.
[6]	YANG W J,WEN Z,DUAN Y,et al.Construction and performance of HTS Maglev launch assist test vehicle[J].IEEE Trans.on Applied Superconductivity,2006,16(2):1108-1111.
[7]	刘宇,杨文将,段毅,等.航天运载器磁悬浮助推发射关键技术[J].北京航空航天大学学报,2006,32(10):1180-1185.LIU Yu,YANG Wenjiang,DUAN Yi,et al.Key technologies of Maglev launch assist for space launch[J].Journal of Beijing University of Aeronautics and Astronautics,2006,32(10):1180-1185.
[8]	恽起麟.风洞试验[M].北京:国防工业出版社,2000.
