旋转半受限单孔冲击局部换热特性实验

毛军逵; 白云峰; 常海萍; 卜继兴

旋转半受限单孔冲击局部换热特性实验

1.
南京航空航天大学能源与动力学院, 南京 210016
2.
空军驻京西地区军代表室北京 100074

基金项目: 国防基础科研资助项目(J1400D001)

计量
- 文章访问数: 1753
- HTML浏览量: 3
- PDF量: 476
- 被引次数: 0
出版历程
- 收稿日期: 2006-09-13
- 修回日期: 2007-01-30
- 刊出日期: 2007-10-28

Experimental investigations on the local heat transfer coefficient of rotating single circular impingement in a half-limited space

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Military Representation in Beijing, Beijing 100074, China

摘要

摘要: 利用热膜法测量局部换热系数Nu,对旋转条件下半受限冲击射流的换热特性开展了实验研究.通过改变冲击雷诺数Re(20 000³5 000)和旋转数Ro(0⁰.003 441)等参数,讨论了旋转状态对半受限单孔冲击换热特性的影响.实验结果表明:旋转显著影响了冲击靶面的局部换热系数分布规律.在实验工况范围内,靶面局部(平均)Nu数均是先随着旋转数Ro的增加而增强,后又随着旋转数Ro的增加而减小.实验中还观察到同静止情况相似,旋转条件下半受限冲击射流的冷却效果也是随着冲击Re的增加而不断提高.
- 航空、航天推进系统 /
- 旋转 /
- 冲击 /
- 换热 /
- 半受限
Abstract: The local heat transfer coefficient Nu of rotating single circular impingement in a half-limited space was studied experimentally.Heated film and thermocouples were used to measure the temperature of target plate and the local heat transfer coefficient Nu was obtained.Jet Reynolds number(Re) of 20 000～35 000 and rotation number(Ro) of 0～0.003 441 were varied to study the heat transfer characteristic of impingement cooling applied under rotating condition.The results show that the Nu is affected greatly by rotation, and the distribution of Nu in rotating condition is quite different from that in stationary condition because of the centrifugal and coriolis forces.With Ro increasing, local and average Nu of target plate increases firstly and then decreases.And the Nu of single circular impingement increases with Re increasing, which is the same as that in stationary case.
- aerospace propulsion system /
- rotating /
- jet impingement /
- heat transfer /
- half-limited mited

HTML

参考文献(10)

[1]	Gardon R,Akfirat J C.The role of turbulence in determining the heat transfer characteristics in impinging jets[J].Journal of Heat and Mass Transfer,1965,8(9):1261-1272.
[2]	Goldstein R J,Timmers J F.Visualization of heat transfer from arrays of impinging jets[J].Journal of Heat and Mass Transfer,1982,25(12):1857-1868.
[3]	Goldstein R J,Sobolik K A,Seol W S.Effect of entrainment on the heat transfer to a heated circular air jet impinging on a flat surface[J].Journal of Heat Transfer,1990,112(3):608-611.
[4]	Jambunathan K,Lai E,Moss M A,et al.A review of heat transfer data for single circular jet impingement[J].Int.Journal of Heat and Fluid flow,1992,13(2):106-115.
[5]	Metzger D E,Grochowsky L D.Heat transfer between an impingement jet and a rotating disk[J].Journal of Heat Transfer,1977,99(4):663-667.
[6]	Metzger D E,Bunker R S,Bosch G.Transient liquid crystal measurement of local heat transfer on a rotating disk with jet impingement[J].Journal of Turbomachinery,1991,113(1):52-59.
[7]	Parsons J A,Han J C.Rotation effect on jet impingement heat transfer in smooth rectangular channels with heated target walls and radially outward cross flow[J].Journal Heat and Mass Transfer,1998,41(13):2059-2071.
[8]	Parsons J A,Han J C,Lee C P.Rotation effect on jet impingement heat transfer in smooth rectangular channels with four heated walls and radially outward cross flow[J].Journal of Turbomachinery,1998,120(1):79-85.
[9]	白云峰.旋转条件下冲击冷却数值模拟及实验研究[D].南京:南京航空航天大学,2005.
[10]	陶文铨.数值传热学[M].西安:西安交通大学出版社,1988.
