喷流反压模拟技术及在高超声速进气道实验中的应用

孙姝; 张红英; 程克明; 伍贻兆

喷流反压模拟技术及在高超声速进气道实验中的应用

南京航空航天大学高超气动研究中心(HARC), 南京 210016

基金项目: 中国博士后基金(0601042B);江苏省博士后基金(20060400935);国防科工委基础预研项目(A2520060219)

计量
- 文章访问数: 1583
- HTML浏览量: 4
- PDF量: 451
- 被引次数: 0
出版历程
- 收稿日期: 2007-05-17
- 修回日期: 2007-08-10
- 刊出日期: 2007-10-28

Back pressure simulation by cavity injection and its application in hypersonic inlet experiment

Hypersonic Aerodynamics Research Center, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为研究高超声速进气道的反压特性以及不起动/再起动特性,提出了一种凹腔喷流反压模拟技术,在实验过程中通过控制阀门的开度可方便地且迅速地调节进气道的出口反压.利用该技术,还对一种马赫数为7级的轴对称高超声速的反压特性及不起动/再起动特性进行了研究,展示了该技术的实用性.结果表明:(1)所提出的凹腔喷流技术可在进气道下游形成较为均匀的、可控的背压环境,因此可用于进气道的反压特性研究;(2)适当调节凹腔的喷流总压,并在实验中实时控制阀门的开度,凹腔喷流技术能够在较短的风洞实验时间内(约8 s)实现进气道起动、不起动、再起动流态之间的切换,因此可用于进气道的不起动/再起动特性研究.
- 航空、航天推进系统 /
- 喷流反压模拟 /
- 高超声速 /
- 进气道 /
- 风洞实验
Abstract: A kind of back pressure simulation technology by cavity injection is brought forward to improve wind tunnel test capability for hypersonic inlets.During wind tunnel test process, the back pressure of inlet can be adjusted rapidly by regulating the valve of injection pipe.Utilizing this specific simulation technology, the performance at different back pressures and the unstarting/restarting characteristics of an axisymmetric inlet are investigated.The design Mach number of the inlet is 7.0.Results indicate:(1) The newly developed simulation technology can form fairly average and easily controllable back pressure downstream the inlet, so it can be used to investigate the back pressure characteristics of hypersonic inlets.(2) By regulating the valve of injection pipe, the simulation technology can realize the switch of hypersonic inlet started state and unstarted state in about 8 milliseconds, so it is suitable to investigate the starting/unstarting/restarting problem of hypersonic inlets.
- aerospace propulsion system /
- back pressure simulation by cavity injection /
- hypersonic /
- inlet /
- wind tunnel test

HTML

参考文献(14)

[1]	William H,Davis P.Hypersonic airbreathing propulsion[M].AIAA Education Series,USA:AIAA Inc,1994.
[2]	Bachchan N,Hillier R.Hypersonic inlet flow analysis at off-design conditions[R].AIAA,2004-5380.
[3]	Carroll B F,Dutton J C.Characteristics of multiple shock wave/turbulent boundary-layer interactions in rectangular ducts[J].Journal of Propulsion Power,1990,6(2):186-193.
[4]	Zanchetta M,Cain T.An axismmetric internal compression inlet[R].AIAA,1998-7957.
[5]	Hsia Y C.Full Navier-Stokes analysis of an axisymmetric scramjet inlet[J].AIAA Journal of Propulsion and Power,1993,9(4):826-833.
[6]	Smart M K.Design of three-dimensional hypersonic inlets with rectangular to elliptical shape transition[J].Journal of Propulsion and Power,1999,15(3):408-416.
[7]	Holland S D.Internal aerodynamics of a generic three-dimensional scramjet inlet at Mach 10[R].AIAA 99-45520.
[8]	尤延铖,梁德旺,黄国平.一种新型内乘波式进气道初步研究[J].推进技术,2006,27(3):252-256.YOU Yancheng,LANG Dewang,HUANG Guoping.Investigation of internal waverider-derived hypersonic inlet[J].Journal of Propulsion Technology,2006,27(3):252-256.
[9]	谭慧俊,郭荣伟.亚、超燃混合模块发动机亚燃模块进气道的M6级高焓风洞实验研究[J].航空学报,2007,28(4):783-790.TAN Huijun,GUO Rongwei.Wind tunnel tests of hypersonic inlets for ramjet modules of ramjet-scramjet combined engine[J].Acta Aeronautica Et Astronautica Sinica,2007,28(4):783-790.
[10]	谭慧俊,郭荣伟.二维弯曲等截面管道中的激波串特性研究[J].航空学报,2006,27(6):1039-1045.TAN Huijun,GUO Rongwei.Characteristics of shock train in two dimensional bends with constant area[J].Acta Aeronautica Et Astronautica Sinica,2007,28(4),:1039-1045.
[11]	范晓樯,李桦,李晓宇,等.高超声速二维进气道参数化设计方法初探[J].航空动力学报,2007,22(1):66-71.FAN Xiaoqiang,LI Hua,LI Xiaoyu,et al.Preliminary investigation on parametric design method of the two-dimensional hypersonic inlet[J].Journal of Aerospace Power,2007,22(1):66-71.
[12]	陈兵,徐旭,蔡国飙.基于遗传算法和空间推进方法的高超声速进气道优化设计研究[J].宇航学报,2006,27(5):1010-1015.CHENG Bing,XU Xu,CAI Guobiao.Optimization design of hypersonic inlets using genetic algorithm based on a parabolized Navier-Stokes flow solver[J],Journal of Astronautics,2006,27(5):1010-1015.
[13]	TAN H J,GUO R W.Experimental study of the unstable-unstarted condition of a hypersonic inlet at Mach 6[J].AIAA Journal of Propulsion and Power,2007,23(4):783-788.
[14]	SUN Shu,ZHANG Hongying.The full flowpath analysis of a hypersonic vehicle[J].Chinese Journal of Aeronantics,2007,20(5):385-393.
