航空发动机稳态总体气动特性的逆向仿真研究
Inverse simulation research on pneumatic characteristic of aeroengines under steady state
-
摘要: 由于缺乏发动机稳态工作的气动参数数据,飞机/发动机气动一体化设计遇到了困难。为此对某型航空发动机的离散试车数据点进行了多元高次多项式拟合,建立了该型号发动机的稳态特性曲线。在此基础上进行了发动机的总体气动性能逆向仿真研究,建立了该型号发动机进出口气动参数随工况变化的关系曲线,为某型飞机的机体/发动机一体化气动设计提供了依据。Abstract: The integral aerodynamic design of aircraft and its propulsion system becomes a difficult task due to the lack of steady pneumatic parameter data of the engine.While the discrete test run data of an aero-engine was adapted using the high order multi-parameters polynomial fit method, the steady characteristic curves were founded.The inverse simulation of pneumatic characteristics for the engine was thus performed, and the state characteristic curves of flow parameters at inlet and outlet of the engine were created, thus providing a basis for integral design of the aircraft and its engine.
-
[1] 赵群力.飞机一体化设计技术[J].航空科学技术,2004,(3):17-20.ZHAO Qunli.Aircraft inte gration design technologies[J].Aeronautical Science and Technology,2004,2004(3):17-20. [2] 曹源,金先龙,孟光.航空发动机系统级仿真研究的回顾与展望[J].航空动力学报,2004,19(4):131-140.CAO Yuan,JIN Xianlong,MENG Guang.Recent development and prospects of system-level modeling of aircraft engine[J].Journal of Aerospace Power,2004,19(4):131-140. [3] Dip.Ingegneria Aeronautica e Spaziale,Politecnico di Torino.A computational method for gas turbine engines[R].AIAA 2005-1009. [4] Reed J A,fjeh A A A.Computational simulation of gas turbine part I-foundation of component-based models[J].Journal of Engineering for Gas Turbines and Power,2000,12(2):366-376. [5] Reed J A,fjeh A A A.Computational simulation of gas turbine partII-extensible domain framework[J].Journal of Engineering for Gas Turbines and Power,2000,12(2):377-38. [6] 封建湖,车刚明,聂玉峰.数值分析原理[M].北京:科学出版社,2004. [7] 王新和,程世洲.曲线拟合的最小二乘法[J].新疆职业大学学报,2004,12(2):86-88.WANG Xinhe,CHENG Shizhou.The method of least squares curve fitting[J].Journal of Xinjing vocational University,2004,12(2):86-88. [8] 高伟,姜水生.分段曲线拟合与离散度加权的数据误差处理方法[J].中国测试技术,2005,31(6):60-61.GAO Wei,JIANG Shuisheng.Method of deal with data error by subsection curve fitting and discrete degree[J].China Measurement Technology,2005,31(6):60-61. [9] 廉小纯,吴虎.航空燃气轮机原理[M].北京:国防工业出版社,2001. [10] (美)William H P,等.C数值算法[M].第2版.北京:电子工业出版社,2004. -
