导弹垂直发射系统三维超声速射流的数值模拟

Numerical simulation on three-dimension supersonic jet of missile vertical launching system

1.
School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
Institute of Chinese Launch Vehicle, Beijing 100076, China

摘要: 对导弹垂直发射系统(VLS,Vertical launching system)内的三维湍流流场进行了数值模拟.采用了单元中心有限体积法和三阶迎风TVD差分格式离散Navier-Stokes方程,采用双时间步和预处理过程提高计算收敛速度,引入对角化的双时间ADI算法求解控制方程.仿真结果准确地模拟了发射系统内的激波形成过程,真实地反映出VLS中的复杂流动.研究表明,压力室底部射流中心的波后压强以大约1 200Hz的频率振荡.
- 航空、航天推进系统 /
- VLS /
- 导弹 /
- 射流 /
- 激波 /
- 双时间步格式 /
- 预处理
Abstract: The three-dimensional turbulent flow fields of missile Vertical launching system(VLS) are computed.Cell-centered finite-volume method and 3rd-order upwind spatial differencing with TVD option is applied for Navier-Stokes governing equations.Dual-time stepping and preconditioning procedure are utilized for improving the calculating convergence velocity. The diagonalized, dual-time ADI algorithm is employed to integrate the governing equations.Shock forming in the plenum chamber is simulated accurately.The complex flow pattern in Vertical Launching System was described veritably.The current studies show that the pressure of jet center at the bottom of plenum chamber oscillates with a frequency about 1200Hz.
- aerospace propulsion system /
- VLS /
- missile /
- jet flow /
- shock wave /
- dual-time stepping scheme /
- preconditioning

[1]	Kulesz J J.MK 41 vertical launching system fleet application[J].Naval Engineers Journal,1985,97(4):174-184.
[2]	Yagla J J,Anderson L P.Internal ballistics and missile launch environment for the vertical Launching system[R].AIAA Paper 1982-0855.
[3]	York B J,Sinha N,Dash S M.Navier-Stokes simulation of plume/vertical launching system Interaction flowfields[R].AIAA Paper 92-0839.
[4]	Douglas A S.Numerical study of unsteadiness in non-reacting and reacting mixing layers[D].Pennsylvania:the Pennsylvania State University,the Graduate School,Department of Mechanical Engineering,1999.
[5]	Coakley T J,Huang P G.Turbulence modeling methods for high speed Flows[R].AIAA87-0286.
[6]	Coakley T J,Huang P G.Turbulence modeling for high speed flows[R].AIAA Paper 92-0436.
[7]	Venkateswaran S,Charles L M.Dual time-stepping and preconditioning for unsteady computations[R].AIAA95-0078.
[8]	Pulliam T H,Chaussee D S.A diagonal from of an lmplicit approximate factorization algorithm[J].Journal of Computational Physics,1981,39:347-363.
[9]	王革,廖伦鹏,杨道伟,等.导弹垂直发射中二次流流场计算[J].宇航学报,1995,16(4):59-65.WANG Ge,LIAO Lunpeng,YANG Daowei,et al.A numerical calculation of secondary flow's flowfield for the missile vertical launching system[J].Journal of Astronautics,1995,16(4):59-65.
[10]	郜冶.舰载导弹垂直发射燃气排导装置的流动和动力特性[D].西安:西北工业大学,1995.
