柔性扑翼微型飞行器升力和推力机理的风洞试验和飞行试验

Aerodynamic experimental investigation for mechanism of lift and thrust of flexible flapping-wing MAV

Research Center of Micro Air Vehicle, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要: 为探讨柔性扑翼微型飞行器产生升力和推力的机理,在研究考虑柔性大变形扑翼气动力计算方法基础上,利用南京航空航天大学低速风洞进行了不同扑动频率、迎角、速度下微型扑翼升力、推力的变化和动态流场显示等风洞实验,并与计算结果进行了比较分析,为微型扑翼机的设计提供了的参考依据.自行研制的微型柔性结构扑翼机成功地进行了飞行试验.
- 航空、航天推进系统 /
- 微型飞行器 /
- 扑翼机 /
- 柔性扑翼 /
- 风洞实验
Abstract: Anew flapping-wing model of MAV(Micro Air Vehicle) with flexible structure was developed in order to explore mechanism of lift and thrust generation in flexible flapping-wing MAV.Wind tunnel test demonstrated the downstroke of the flapping-wing by utilizing laser instrument.Variation of the lift and thrust of flexible flapping-wing under conditions of different flap parameters such as flap frequency,angle of attach,flow speed and so on was investigated and compared with computed results.The research provides reference for design of flapping-wing MAV.The flight tests of the Flexible Flapping-wing MAVconducted in Research Center of MAVof NUAAwere also successfully completed.
- aerospace propulsion system /
- micro air vehicle(MAV) /
- flapping-wings /
- flexible flapping-wing /
- wind tunnel experiment.

[1]	James M M,Michael S F.Micro air vehicles-toward a new dimension in flight[R].USDARPA/TTO Report,1997.
[2]	Platzer M F,Jones K D,Lund T G.Experimental and computational investigation of flapping wing propulsion for micro-air vehicles[R].Symposium of Low-Reynolds Number Vehicles,University of Notre Dame,Indiana:2000.
[3]	曾锐,昂海松.仿鸟复合振动的扑翼气动分析[J].南京航空航天大学学报,2003,5(1):6-12.ZENG Rui,ANG Haisong.Aerodynamic computation of flapping-wing simulating bird wings[J].J.of Nanjing University of Aeronautics & Astronautics.2003,5(1):6-12.
[4]	曾锐,昂海松,刘国涛.柔性扑翼模型建立及其功率研究[J].中山大学学报,2004,43(3):28-35.ZENG Rui,ANG Haisong,LIU Guotao.The model and power of flexibel flapping-wing,Acta Scientiarum Naturalium Universitatis Sunyatseni,2004,43(3):28-35.
[5]	白存儒,钟诚文,李为吉,等.微型扑翼机风洞试验探索性研究[J].流体力学实验与测量,2003,17:77-40.BAI Cunru,ZHONG Chengwen,LI Weiji,et al.The wind tunnel test of flapping-wing MAV[J].Experiment and Measure of Fliud Mechanics,2003,17:77-40.
[6]	Mueller T J.Fixed and flapping wing aerodynamics for micro air vehicle applications[M].[s.l.]:Published by the American Inseitute of Aeronautics and Astronautics Inc,2002.
