不同顶部间隙对跨声风扇转子的影响分析

刘建勇; 袁巍; 周盛; 陆亚钧

不同顶部间隙对跨声风扇转子的影响分析

北京航空航天大学能源与动力工程学院航空发动机气动热力重点实验室, 北京 100083

基金项目: 国家自然科学基金(50476003)

计量
- 文章访问数: 1751
- HTML浏览量: 251
- PDF量: 464
- 被引次数: 0
出版历程
- 收稿日期: 2006-11-15
- 修回日期: 2007-01-23
- 刊出日期: 2007-11-28

Analysis for influence of different tip clearance on transonic fan rotor

National Key Laboratory on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 为研究跨声压气机叶尖间隙流动对性能影响的特征,数值计算了某高负荷跨声风扇转子在种等高间隙和两种阶梯间隙结构下的性能.通过对总体性能参数和叶尖区静压、周向速度、熵等细节参数的分析,认为叶尖前段间隙流比后段间隙流对压气机性能的影响更大.其中,涡波干涉对于前段间隙流带来的危害尤为重要.比较阶梯间隙的计算结果,验证了这一推断.
- 航空、航天推进系统 /
- 跨声压气机 /
- 叶尖间隙 /
- 涡波干涉
Abstract: In order to study the influence of tip clearance flow on the performance of a transonic compressor,a high-load transonic fan's rotor with five constant width clearances and two step-clearances were numerically simulated.After analysis of the overall performance parameters and the detailed flow parameters including the static pressure,circumferential velocity and entropy,it is concluded that the front part clearance flow has greater influence on the compressor than the back part clearance flow.In particular,the vortex-shock interference may worsen the front part clearance flow,as demonstrated by comparing the simulation of two step-clearances.
- aerospace propulsion system /
- transonic compressor /
- tip clearance /
- vortex-shock interference

HTML

参考文献(8)

[1]	Wilke I,Kau H P.A numerical investigation of the flow mechanisms in a HPC front stage with axial slots[R].ASME Paper GT2003-38481,2003.
[2]	吴艳辉,楚武利,刘志伟.轴流压气机转子性能及间隙流动研究[J].西北工业大学学报,2005,23(6):737-741.WU Yanhui,CHU Wuli,LIU Zhiwei.On detailed structure of tip clearance flow in an isolated axial flow compressor rotor and its effect on compressor performance[J].Journal of Northwestern Polytechnical University,2005,23(6):737-741.
[3]	Beheshti B H,Teixeira J R,Ivey P C,et al.Parametric study of tip clearance-casing treatment on performance and stability of a transonic axial compressor[R].ASME Paper GT2004-53390,2004.
[4]	Wilke I,Kau H P.A numerical investigation of the influence of casing treatments on the tip leakage flow in a HPC front stage[R].ASME Paper GT2002-30642,2002.
[5]	Brandt H,Fottner L,Saathoff H,et al.Effects of the inlet flow conditions on the tip clearance flow of an isolated compressor rotor[R].ASME Paper GT2002-30639,2002.
[6]	Roy B,Chouhan M,Kaundinya K V.Experimental study of boundary layer control through tip injection on straight and swept compressor blades[R].ASME Paper GT2005-68304,2005.
[7]	祁明旭,丰镇平.透平动叶顶部间隙流的端壁二次流结构研究[J].西安交通大学学报,2005,39(5):445-449.QI Mingxu,FENG Zhenping.Study on tip clearance flow of turbine blade-endwall secondary flow structure[J].Journal of Xi'an Jiaotong University,2005,39(5):445-449.
[8]	Rabe D C,Hah C.Application of casing circumferential grooves for improved stall margin in a transonic axial compressor[R].ASME Paper GT2002-30641,2002.
