跨声速涡轮叶栅三维流场的数值模拟

Numerical simulation of the three-dimensional flow field of transonic turbine cascade

1.
College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
Gas Turbine Establishment of China, Chengdu 610500, China

摘要: 以具有试验测量数据的一个高压涡轮动叶中截面平面叶栅和一个高压涡轮导向器环形叶栅为对象,采用计算流体动力学(CFD)软件CFX-TASCflow,对两个涡轮叶栅的跨声速三维粘性流场进行了数值计算,验证了CFX-TASCflow软件在航空燃气涡轮设计计算中的可靠性,并对所研究的跨声速涡轮叶栅粘性流场进行了分析.
- 航空、航天推进系统 /
- 计算流体动力学(CFD) /
- N-S方程 /
- 涡轮叶栅 /
- 湍流模型
Abstract: Athree-dimensional Navier-Stokes simulation was performed numerically for a transonic turbine planar cascade and a transonic turbine annular cascade using CFDsoftware CFX-TASCflow code.The results show that CFX-TASCflow code software could predict reliably turbine cascade flow field and its performance.The characteristics of the researched transonic turbine cascades viscous flow field were analyzed.
- aerospace propulsion system /
- computational fluid dynamics(CFD) /
- N-S equations /
- turbine cascade /
- turbulence model

[1]	Denton J D.The calculation of three-dimensional viscous flow through multistage turbomachines[J].ASME Journal of Turbomachinery,1992,114,18-26.
[2]	Adamczyk J J.Aerodynamic analysis of multistage turbomachinery flows in support of aerodynamic design[R].ASME 99-GT-80,1999.
[3]	CFX-TASCflow User Documentation[M].Canada:AEA Technology Engineering Software Ltd.,1998.
[4]	Numeca-user's Help[M].Belgium:Numeca International Co.2006.
[5]	韩占忠,王敬,兰小平.Fluent流体工程仿真计算--实例与应用[M],北京:北京理工大学出版社,2004.
[6]	陈懋章.叶轮机气动力学研究及其发展趋势[C]∥中国航空学会航空百年学术论坛.北京:中国航空学会动力专业分会,2003,10.
[7]	Jiang Z L.Experimental investigation of high pressure turbine cascade (G3)[R].GTE YGH-019-W017,1999,11.
[8]	Sieverding C H,Art T,Denos R,et al.Investigation of the flow field downstream of a turbine trailing edge coolant nozzle guide vane[R].ASME 94-GT-209.
[9]	CFX-TurboGrid User Documentation[M].Canada:AEA Technology Engineering Software Ltd.,1998.
[10]	Zeng J,Cheng X H.Numerical simulating of a transonic turbine cascade with trailing edge coolant ejection[C]∥The 3rd ISAIF,Germany:[s.n.],2000,9.
