粒子分离器涡流叶片鸟撞击损伤试验

关玉璞; 张在坤; 赵振华; 陈伟; 高德平

粒子分离器涡流叶片鸟撞击损伤试验

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1433
- HTML浏览量: 54
- PDF量: 483
- 被引次数: 0
出版历程
- 收稿日期: 2007-05-14
- 修回日期: 2007-07-24
- 刊出日期: 2007-12-28

Experimental study on bird damage of vortex vane in the particle separator

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 研究粒子分离器涡流叶片受鸟撞击损伤规律,提高粒子分离器抗外物损伤设计能力.通过外物冲击损伤试验方法,研究了模拟鸟撞击粒子分离器涡流叶片的过程.采用瞬态响应测试系统,获得了模拟鸟撞击涡流叶片的应变-时间历程.对采集到的曲线和数据进行了分析.利用三坐标测量仪,测得撞击前后涡流叶片叶型;经过比较计算,得到了涡流叶片的变形.模拟鸟以Ma=0.2速度撞击涡流叶片时,涡流叶片产生了塑性应变,变形很大.
- 航空、航天推进系统 /
- 涡流叶片 /
- 应变 /
- 撞击试验 /
- 冲击动力学 /
- 粒子分离器
Abstract: The rule of damage on the vortex vane in the particle separator caused by bird impact was studied with a view to improve the resistance design of particle separator to foreign object damage.By the method of experiment on impact damage,the process in which the vortex vane in the particle separator is impacted by a model bird was researched.By using the system of measurement and test on transient response,the strain-time history of the vortex vane impacted by model bird was gained.Profile of the vortex vane before and after the impact inflicted by the model bird was obtained with a three-coordinate device.Through comparison and calculation the deformation of the vortex vane after the model bird impact was gained.It is found that plastic strain in the vortex vane emerges and the deformation of the vortex vane is very large when the model bird impacts the vortex vane at the velocity Ma=0.2.
- aerospace propulsion system /
- vortex vane /
- strain /
- impact experiment /
- impact dynamics /
- particle separator

HTML

参考文献(4)

[1]	范文正,于海滨.直升机进气防护装置的现状和发展趋势[J].航空科学技术,2000,(1):31-32.FAN Wenzheng,YU Haibin.Status and trends of the inlet preventer of helicopter[J].Aeronautical Science and Technology,2000,(1):31-32.
[2]	关玉璞,陈伟,高德平.航空发动机叶片外物损伤研究现状[J].航空学报,2007,28(4):851-857.GUAN Yupu,CHEN Wei,GAO Deping.Present status of investigation for foreign object damage to blade in aeroengine[J].Acta Aeronautical et Astronautica Sinica,2007,28(4):851-857.
[3]	王金贵.气体炮原理及技术[M].北京:国防工业出版社,2001:40-56.WANG Jingui.Principle and technology[M].Beijing:National Defense Industry Press,2001:40-56.
[4]	武存浩,杨嘉陵,臧曙光,等.鸟撞高速摄影试验与过程研究[J].北京航空航天大学学报,2001,27(3):332-335.WU Cunhao,YANG Jialing,ZANG Shuguang,et al.Study of bird impact loading model[J].Journal of Beijing University of Aeronautics and Astronautics,2001,27(3):332-335.
