等离子涂层涡轮导向叶片热疲劳寿命预测研究

魏洪亮; 杨晓光; 齐红宇

等离子涂层涡轮导向叶片热疲劳寿命预测研究

北京航空航天大学能源与动力工程学院, 北京 100083

计量
- 文章访问数: 2339
- HTML浏览量: 319
- PDF量: 477
- 被引次数: 0
出版历程
- 收稿日期: 2006-12-07
- 修回日期: 2007-06-01
- 刊出日期: 2008-01-28

Study on thermal fatigue life prediction for plasma sprayed thermal barrier coatings on the surface of turbine vane

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 针对等离子涂层涡轮导向叶片材料的变形特点,引入了粘塑性本构模型.进行了涂层高温氧化实验、带涂层构件热疲劳实验及有限元模拟研究.基于研究结果,建立了可以体现氧化损伤与热疲劳损伤耦合效应的寿命预测模型.计算分析了带涂层涡轮导向叶片的稳态温度场、涂层隔热效果和基于宏观尺度的应力应变场,研究了宏、细观有限元计算结果间的转换关系,提出了等效系数的方法,对涡轮导向叶片表面涂层的热疲劳寿命进行了预测.寿命预测结果合理,方法可行.
- 航空、航天推进系统 /
- 等离子热障涂层 /
- 涡轮导向叶片 /
- 粘塑性 /
- 本构方程 /
- 热疲劳 /
- 寿命预测
Abstract: According to the deformation characteristics of plasma sprayed ceramic thermal barrier coatings(TBC) and directional solidified superalloy substrate,viscoplastic constitutive models were introduced.Static oxidation test and thermal fatigue test of thermal barrier coating structures were conducted along with related FEManalysis.Alife prediction model for TBCwas established for presenting the coupling effect of oxidation damage and thermal fatigue damage.The steady temperature field,thermal barrier effect,and the macro-scale stress/strain fields of 3-dimensional turbine vane with TBCwere calculated and analyzed.The relationship between macro and micro-scale under scanning electronic microscopy of FEM(Finite Element Method) results was investigated.Amethod of equivalent coefficient was proposed while the thermal fatigue life for TBCon the surface of turbine vane was predicted,showing that the life prediction results are reasonable and the method is feasible.
- aerospace propulsion system /
- plasma sprayed thermal barrier coatings /
- turbine vane /
- viscoplasticity /
- constitutive theory /
- thermal fatigue /
- life prediction

HTML

参考文献(12)

[1]	Busso E P,Lin J,Sakurai S,et al.A mechanistic study of oxidation-induced degradation in a plasma-sprayed thermal barrier coating system.Part Ⅱ:Life prediction model[J].Acta Materialia,2001,49:1529-1536.
[2]	Freborg A M,Ferguson B L,Brindley W J,et al.Modeling oxidation induced stresses in thermal barrier coatings[J].Mater.Sci.Eng.A,1998,A245(3):182-190.
[3]	Karlsson A M,Hutchinson J W,Evans A G.A fundamental model of cyclic instabilities in thermal barrier systems[J].Journal of the Mechanics and Physics of Solids,2002,50:1565-1589.
[4]	Demasi J T,Sheffler K D,Ortiz M.Thermal barrier coating life prediction model development[R].NASA-CR-182230,1989.
[5]	Evans A G,Mumm D R,Hutchinson J W,et al.Mechanisms controlling the durability of thermal barrier coatings[J].Progress in Materials Science,2001,46:505-553.
[6]	Janosik L A,Duffy S F.A viscoplastic constitutive theory for monolithic ceramics-Ⅰ[J].ASME J.Eng.Gas Turbines Power,1998,120:155-161.
[7]	XIE Wangang,Walker K P,Jordan E H,et al.Implementation of a viscoplastic model for a plasma sprayed ceramic thermal barrier coating[J].J Eng Mater Technol,2003,125:200-207.
[8]	Chaboche J L.Constitutive equations for cyclic plasticity and cyclic viscoplasticity[J].International Journal of Plasticity,1989,5:247-302.
[9]	Han S L,Li S X,Smith D J.Comparison of phenomenological and crystallographic models for single crystal nickel base superalloys.Ⅰ.Analytical identification[J].Mechanics of Materials,2001,33:251-266.
[10]	耿瑞.热障涂层强度分析及寿命预测研究[D].北京:北京航空航天大学,2001.GENG Rui.Strength analysis and life prediction study on thermal barrier coatings[D].Beijing:Beijing University of Aeronautics and Astronautics,1990.
[11]	Meier S M,Nissley D M,Sheffler K D.Thermal barrier coating life prediction model development,Phase Ⅱ Final Report[R].NASA-CR-189111,1991.
[12]	Rabiei A,Evans A G.Failure mechanisms associated with the thermally grown oxide in plasma-sprayed thermal barrier coatings[J].Acta Mater,2000,48:3963-3976.
