叶片振动应力的叶根振动监测法及实现技术
Blade-root vibration monitoring method for blade vibration stress monitoring and its implementation techniques
-
摘要: 提出一种航空螺旋桨叶片振动应力监测方法—叶根振动监测法,通过监测螺旋桨振动来获得叶根振动激励,建立叶片振动计算传递矩阵模型,并由叶根激励振动计算叶片的振动响应和振动应力,进而实现对叶片振动应力的监测.叶根振动可以通过直接测量或由螺旋桨转子支承机匣监测振动换算获得.最后,通过对比桨叶振动应力的计算结果与飞行试验实测结果验证该方法.结果表明,叶根振动监测法简便、易行,可以进一步应用.Abstract: This paper puts forward a method for monitoring aero-propeller blade vibration stress-the blade-root vibration monitoring method.We can obtain the blade root vibration excitation by monitoring propeller vibration and establish a transfer matrix model for blade vibration calculation,and then calculate the vibratory response and stress of the blade.In this way the blade vibration stress monitoring can be realized.The blade root vibration parameters may be acquired by direct measurement or by calculating with the measured vibration at the bearing case of the propeller rotator.Finally,this method is verified by checking the calculated results against the measured results in flight test.The results show that the blade root vibration monitoring method is simple and feasible in engineering applications.
-
[1] 凯巴ИВ.航空燃气涡轮发动机技术诊断[M].王起鹏,刘德馨,译.北京:航空工业出版社,1990. [2] 吕文林.航空发动机强度计算[M].北京:国防工业出版社,1988. [3] 屈玉池.某型螺旋桨试飞应力载荷测量[R].西安:中国飞行试验研究院,1997. [4] 屈玉池,白向利,张永峰.空气螺旋桨应力载荷飞行试验研究[J].飞行力学,2006,24(4):88-90.QU Yuchi,BAI Xiangli,ZHANG Yongfeng.Flight test study of stress loads for an air propeller[J].Flight Dynsmics,2006,24(4):88-90. [5] 方同,薛璞.振动理论及应用[M].西安:西北工业大学出版社,1998. [6] 哈里斯C M,克瑞得C E.冲击和振动手册[M].众师,译.北京:科学出版社,1999. [7] 王国治,温华兵.鱼雷结构振动传递特性的试验研究[J].实验力学,2001,16(2):188-195.WANG Guozhi,WEN Huabing.Experimental study of the structural vibration transfer characteristics of the torpedo[J].Journal of Experimental Mechanics,2001,16(2):188-195. -
