不同气体对涡流管能量分离效果的影响

张国庆; 吴玉庭; 丁雨; 马重芳

不同气体对涡流管能量分离效果的影响

北京工业大学环境与能源工程学院, 传热强化与过程节能教育部重点实验室, 北京 100022

基金项目: 国家重点基础研究发展计划(973)资助

计量
- 文章访问数: 1636
- HTML浏览量: 83
- PDF量: 410
- 被引次数: 0
出版历程
- 收稿日期: 2006-10-24
- 修回日期: 2007-01-31
- 刊出日期: 2008-01-28

Effect of various gases on the energy separation performance of vortex tube

Key Laboratory of Ministry of Education on Enhanced Heat Transfer and Energy Conservation, College of Environmental and Energy Engineering, Beijing University of Technology, Beijing 100022, China

摘要

摘要: 通过实验的方法,分别对以空气、氮气、氩气和二氧化碳等气体为工质的涡流管的能量分离效应进行了研究,得出了涡流管的冷热效应、制冷量、单位制冷量和COP(性能系数,CoefficientofPerformance)随冷流率变化的特性曲线.研究表明:涡流管的冷热效应与工质的摩尔质量有着重要的关系,摩尔质量越大,其制冷和制热性能就越好;另外,在一定程度上还受气体本身的焦耳-汤姆逊系数的影响.对于制冷量和COP,除了跟工质的制冷效应和比热容有关外,跟摩尔质量也存在着相应的正比关系.
- 涡流管 /
- 性能系数(COP) /
- 摩尔质量 /
- 焦耳-汤姆逊系数
Abstract: The energy separation performance of the vortex tube with various gases,such as air,nitrogen,argon and carbon dioxide,was studied in the experiment,whereby cold and hot characteristic curves,refrigeration output,unit refrigeration output and coefficient of performance(COP) versus cold flow rate were obtained.The results indicate that cold and hot effects are closely related to mol mass: the bigger the mol mass,the better the cold and hot performance will be;additionally,these effects are subjected to the coefficient of Joule-Thomson to some extent.Refrigeration output and COPalso have a corresponding direct correlation with mol mass,in addition to refrigeration effect and specific heat at constant pressure.
- vortex tube /
- coefficient of performance(COP) /
- mol mass /
- coefficient of Joule-Thomson

HTML

参考文献(4)

[1]	Soni Y,Thomson W J.Optimal design of the Ranque-Hilsch vortex tube[J].J Heat Transfer,1975,97C:316-317.
[2]	Gao C M,Bosschaart K J.Experimental study on a simple Ranque-Hilsch vortex tube[J].Cryogenics,2005,45:173-183.
[3]	Ranque G J.Method and apparatus for obtaining from a fluid under pressure two currents of fluid at different temperatures[Z].United States Patent 1952281,March 27,1934.
[4]	姜曙,叶芳,俞坚,等.三流道喷嘴涡流管能量分离特性的研究[J].工程热物理学报,2004,25(3):499-501.JING Shu,YE Fang,YU Jian,et al.The performance study on energy separation in vortex tube of tri-channels[J].Journal of Engineering Thermophysics,2004,25(3):499-501.
