高速圆柱滚子轴承工作温度研究

王黎钦; 陈观慈; 古乐; 郑德志

高速圆柱滚子轴承工作温度研究

哈尔滨工业大学机电学院哈尔滨 150001

基金项目: 国家自然科学基金(50605014);国家973计划(2007CB607602)

计量
- 文章访问数: 1915
- HTML浏览量: 168
- PDF量: 471
- 被引次数: 0
出版历程
- 收稿日期: 2006-12-30
- 修回日期: 2007-04-27
- 刊出日期: 2008-01-28

Study on operating temperature of high-speed cylindrical roller bearings

School of Mechatronics Engineering, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 将滚子与套圈滚道摩擦生热视为移动热源,建立了高速圆柱滚子轴承温度场计算模型;使用ANSYS的APDL语言发展了轴承工作温度分析的参数化程序,输入热流密度等边界条件,程序能够自动建模精确的分析高速圆柱滚子轴承工作温度.以一个型号轴承为例,分析了不同工况参数对轴承工作温度的影响,结果显示轴承内圈转速、径向载荷和润滑油入口油温对轴承工作温度影响显著.
- 航空、航天推进系统 /
- 圆柱滚子轴承 /
- 工作温度 /
- 轴承生热 /
- 移动热源
Abstract: Heat generation between rollers and raceways treated as moving heat source,a model for calculating the temperature field of a high-speed cylindrical roller bearing was set up.Aparametrical code has been developed with the APDLlanguage of ANSYS.Using this code,the operating temperature of cylindrical roller bearings with different types of lubricants can be obtained more accurately when boundary conditions such as heat flux are input.Taking one model of bearing as an example,effects of various operating parameters on operating temperature have been analyzed.It is shown that the rotational speed of the inner ring,the radial load and the inlet temperature of the lubricant have a great influence on operating temperature of the bearing.
- aerospace propulsion system /
- cylindrical roller bearing /
- operating temperature /
- heat generation /
- moving heat source

HTML

参考文献(13)

[1]	焦育洁,吕新生,张锡昌.航空发动机主轴圆柱滚子轴承典型故障分析[J].轴承,2003,12:29-30.JIAO Yujie,LU Xinsheng,ZHANG Xichang.Typical fault analysis of cylindrical roller bearing in the aero-engine shaft[J].Bearing,2003,12:29-30.
[2]	Blok H.Surface temperatures under extreme pressure lubricating conditions[R].Omnes,Paris:Second World Petroleum Conference,1937.
[3]	Jaeger J C.Moving surfaces of heat and the temperature at sliding contacts[J].Proc.R.Soc.N.S.W.,1942,56:203-224.
[4]	Kim K H,Sadaghi F.Three-dimensional temperature distribution in EHD Lubrication:Part Ⅰ-Circular contact[J].Tribology,1992,114:32-41.
[5]	Ma M T.An expedient approach to the non-newtonian thermal EHL in heavily loaded point contacts[J].Wear,1977,206:100-112.
[6]	Liu X L,Jiang M,Yang P.Non-newtonian thermal analyses of point EHL contacts using the eyring model[J].Tribology,2005,127:70-81.
[7]	Kannel J W,Barber S A.Estimate of surface temperature during rolling contact[J].Tribology Transaction,1989,32(3):305-310.
[8]	Brown J R,Forster N H.Operating temperatures in lubricated rolling element hearings for gas turbines[R].AIAA-2000-3027.2000:1268-1275.
[9]	何晓亮,熊万里,黄红武.高速精密主轴轴承热特性的计算及分析[J].机械,2003,30(6):14-16.HE Xiaoliang,XIONG Wanli,HUANG Hongwu.Analysis and calculation on the thermal behavior of precision high-speed spindle bearing[J].Machinery,2003,30(6):14-16.
[10]	蒋兴奇,马家驹,赵联春.高速精密角接触球轴承热分析[J].轴承,2000,(8):1-4.JIANG Xingqi,MA Jiaju,ZHAO Lianchun.Thermal analysis for high speed precision angular contact ball bearing[J].Bearing,2000,(8):1-4.
[11]	Harris T A.Rolling bearing analysis[M].3rd ed.New York:John Wiley and Sons,Inc.1990.
[12]	Poplawski J V.Slip and cage forces in a high-speed rolle,bearing[J].Journal of Lubrication Technology,1972:143-152.
[13]	Gupta P K.Advanced dynamics of rolling elements[M].New York:Springer-Verlag New York Inc,1984.
