基于传动性能和垂直轮位的弧齿锥齿轮齿面设计

基金项目: 航空科学基金(04C53015);国家自然科学基金(50475148);河南科技大学青年基金(2006QN027)

Tooth surface design of spiral bevel gears based on meshing performances and work offset

1.
School of Mechanical and Electronical Enginerring, Northwestern Polytechnical University, Xi'an 710072, China
2.
Zhongnan Transmission Machinery Works of Changsha Aviation Industry, Changsha 410200, China
3.
China Aviation Power Plant Research Institute, Zhuzhou 412202, China

摘要: 根据齿面印痕的位置、方向及传动误差幅值的要求,在齿面上设计三个啮合点,通过对这三个啮合点的控制,达到对齿面啮合质量的全程控制.为了满足不同的加工要求,在此基础上,按照给定的垂直轮位的值对小轮加工参数进行再设计,保证传动误差的幅值不变且接触迹线仅有较小的改变.最后分别用该方法和美国Gleason公司的软件设计一对齿轮,并进行齿面印痕、传动误差和齿面对比,两种设计是基本一致的.
- 航空、航天推进系统 /
- 弧齿锥齿轮 /
- 传动误差 /
- 齿面印痕 /
- 垂直轮位
Abstract: Three meshing points on the tooth surface were designed according to the contact pattern and transmission errors.The meshing quality was controlled exactly through control of these three meshing points.To meet different processing demands,the processing parameters of pinion was redesigned according to the given value of work offset,thus maintaining the magnitude of transmission error with little variation of contact pattern.In the end,a pair of gears was designed by Gleason software and this approach respectively,showing the consistency of these two designs by comparing the tooth surface,contact pattern and transmission errors.
- aerospace propulsion system /
- spiral bevel gears /
- transmission errors /
- contact pattern /
- work offset

[1]	曾韬.螺旋锥齿轮设计与加工[M],哈尔滨:哈尔滨工业大学出版社,1989:260-298.
[2]	Litvin F L.Local synthesis and tooth analysis of facemilled of spiral bevel gears[R].NASA CR4342,1990.
[3]	吴训成.点啮合齿面主动设计理论和方法[J].机械科学与技术,2000,19(3):347-349.WU Xuncheng.On function-oriented design of point-contact tooth surfaces[J].Mechanical Science and Technology,2000,19(3):347-349.
[4]	方宗德.基于传动误差设计的弧齿锥齿轮啮合分析[J].航空学报,2002,23(3):226-230.FANG Zongde.Tooth contact analysis of spiral bevel gears based on the design of transmission error[J].Acta Aeronautica et Astronautica Sinica,2002,23(3):226-230.
[5]	方宗德.高重合度螺旋锥齿轮的设计与仿真[J].西北工业大学学报,2002,20(2):213-217.FANG Zongde.Design and simulation On hypoid and spiral bevel gears with high contact ratio[J].Journal of Northwestern Polytechnical University,2002,20(2):213-217.
[6]	方宗德,杨宏斌,周彦伟.高速弧齿锥齿轮动态啮合质量优化[J].航空学报,2001,22(1):69-77.FANG Zongde,YANG Hongbin,ZHOU Yanwei.Optimization of dynamic meshing behavior of high speed spiral bevel gears[J].Acta Aeronautica et Astronautica Sinica,2001,22(1):69-77.
[7]	Litvin F L.Computerized design,simulation of meshing,and contact and stress analysis of face-milled formate generated spiral bevel gears[J].Mechanism and Machine Theory,2002,37(2):441-459.
