采用流固耦合方法的整级叶片鸟撞击数值模拟

蒋向华; 王延荣

采用流固耦合方法的整级叶片鸟撞击数值模拟

北京航空航天大学能源与动力工程学院航空发动机数值仿真研究中心, 北京 100083

计量
- 文章访问数: 1789
- HTML浏览量: 302
- PDF量: 437
- 被引次数: 0
出版历程
- 收稿日期: 2007-01-29
- 修回日期: 2007-07-02
- 刊出日期: 2008-02-28

Numerical simulation of bird impact on bladed rotor stage by fluid-solid coupling method

Aeroengine Numerical Simulation Research Center, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 利用MSC.DYTRAN软件建立了鸟撞航空发动机叶片转子级瞬态动力学有限元模型,采用流固耦合算法,模拟受气动和离心载荷作用并稳定旋转的发动机转子叶片,遭受不同鸟体撞击的瞬态响应过程.计算结果表明:鸟体撞击会使叶片产生巨大的瞬时冲击应力;鸟体速度、密度和尺寸的增加,将迅速增加叶片的冲击应力峰值,当叶片硬化和变形能力达到充分发展后,冲击应力峰值的增加速度会变慢;同时,叶片材料静态硬化模量的增加也会提高冲击应力峰值,而静态屈服强度的增加则会减小冲击峰的作用时间.最后还进一步模拟了鸟撞使叶片发生失效破坏的过程.
- 航空、航天推进系统 /
- 鸟撞 /
- 瞬态响应 /
- 流固耦合
Abstract: An aeroengine rotor stage finite element method(FEM) model with aerodynamic load and constant rotational speed was studied by using fluid-solid coupling method with MSC.DYTRANsoftware in this paper to investigate its transient dynamic response while suffering various bird impacts.Results show that great instantaneous impact stress exists in the blades during the swift impact.The peak stress will rapidly increase if the velocity,density and size of the bird increase;nevertheless this ascendant tendency can be blunted after the potential of material hardening and deformation abilities have sufficiently developed.The result also reveal that raising hardening modulus of the blade material can increase the impact stress as well,whereas raising material yield strength will reduce the action time of impact stress.Finally,a more complicated simulation,in which material failure was included,was carried out to investigate the process of blade failure caused by bird impact.
- aerospace propulsion system /
- bird impact /
- transient response /
- fluid-solid coupling

HTML

参考文献(17)

[1]	朱俊,李玉龙.飞机鸟撞试验瞬时速度的连续测试方法研究[J].测控技术,2003,22(12):5-7.ZHU Jun,LI Yulong.Research for the instantaneous velocity measurement in aircraft bird-impact test[J].Measurement & Control Technology,2003,22(12):5-7.
[2]	刘大响,陈光.航空发动机--飞机的心脏[M].北京:航空工业出版社,2003:159-160.
[3]	Horsley J.The Rolls-Royce way of validating fan integrity[R].AIAA-93-2602,1993.
[4]	张志林,姚卫星.飞机风挡鸟撞动响应分析方法研究[J].航空学报,2004,25(6):577-580.ZHANG Zhilin,YAO Weixing.Research on dynamic analysis of bird impact on aircraft windshield[J].Acta Aeronautica et Astronautica Sinica,2004,25(6):577-580.
[5]	武存浩,杨嘉陵,臧曙光,等.鸟撞高速摄影试验与过程研究[J].北京航空航天大学学报,2001,27(3):332-335.WU Cunhao,YANG Jialing,ZHANG Shuguang,et al.Study of bird impact loading model[J].Journal of Beijing University of Aeronautics and Astronautics,2001,27(3):332-335.
[6]	McCarty R E.MAGNA computer simulation of bird impact on the TF-15 aircraft canopy[R].ADA140701,1983.
[7]	谢宗蕻,卞文杰,昂海松,等.峰窝夹芯结构雷达罩鸟撞有限元分析与模拟[J].爆炸与冲击,1999,19(3):236-242.XIE Zhonghonga,BIAN Wenjie,AN Haisong,et al.The FEM analysis and simulation of bird impact radome with composite sandwich structure[J].Explosion and Shockwaves,1999,19(3):236-242.
[8]	姚小虎,韩强,张晓晴,等,飞机圆弧风挡抗鸟撞试验研究[J].爆炸与冲击,2005,25(5):471-422.YAO Xiaohu,HAN Qiang,ZHANG Xiaoqing,et al.Experimental study on arc windshield of fighter subjected to bird Impact[J].Explosion and Shockwaves,2005,25(5):471-422.
[9]	Audic S,Berthillier M,Bonini J.Prediction of bird impact in hollow fan blades[R].AIAA-2000-3201,2000.
[10]	Boroughs R R.High speed bird impact analysis of the Learjet 45 windshield using DYNA3D[R].AIAA-98-1705,1998.
[11]	Stoll F,Brockman R A.Finite element simulation of highspeed soft-body impacts[R].AIAA-97-1093,1997.@[12]Birkbeck J C.Effects of FOD on the fatigue crack initiation of ballistically impacted Ti-6Al-4V simulated engine blades[D].Dayton,Ohio:University of Dayton,2002.8.
[12]	Birkbeck J C.Effects of FOD on the fatigue crack initiation of ballistically impacted Ti-6Al-4V simulated engine blades[D].Dayton,Ohio:University of Dayton,2002.8.
[13]	Xi Chen.Foreign object damage and fatigue cracking[D].Cambridge,Massachusetts:Harvard University,2001.5.
[14]	Boyce B L.Understanding impact-induced fatigue failure[D].USA:University of California,2001.
[15]	黄志勇,陈伟,赵海欧,等.评定叶片鸟撞击损伤的参数与方法[J].航空发动机,2005,31(1):28-30.HUANG Zhiyong,CHENG Wei,ZHAO Haiou,et al.Parameters and methods for evaluating bird impact damage of fan/compressor blade[J].Aeroengine,2005,31(1):28-30.
[16]	卞文杰,万力,吴莘馨.瞬态动力学CAE解决方案MSC.Dytran基础教程[M].北京:北京大学出版社,2004,1-15.
[17]	梁春华.商用飞机发动机几项关键新技术[J].国际航空,2002,(9):53-54.LIANG Chunhua.New technologies used for commercial aircraft engines[J].International Aviation,2002,(9):53-54.
