低温推进剂贮箱增压系统分布参数数值仿真(Ⅱ)增压系统数值模型与仿真结果

陈阳; 张振鹏; 杨思锋; 瞿骞; 陈锋; 朱子环

低温推进剂贮箱增压系统分布参数数值仿真(Ⅱ)增压系统数值模型与仿真结果

1.
北京航空航天大学宇航学院, 北京 100083
2.
北京航天试验技术研究所, 北京 100074

计量
- 文章访问数: 1621
- HTML浏览量: 0
- PDF量: 434
- 被引次数: 0
出版历程
- 收稿日期: 2007-01-15
- 修回日期: 2007-05-15
- 刊出日期: 2008-02-28

Distributed parameter numerical simulation for the transients of cryogenic propellant tank pressurization system (Ⅱ) Numerical model and simulation results of pressurization system

1.
School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
Beijing Institute of Aerospace Testing Technology, Beijing 100074, China

摘要

摘要: 在所建立低温推进剂分布参数贮箱模型的基础上,采用液体火箭发动机试验台气路系统模块化建模与仿真软件,对某试验台液氧贮箱增压系统在发动机点火工作段的增压过程进行了仿真研究.仿真结果与试验结果以及经验公式计算结果获得了很好的一致,表明分布参数贮箱模型相对于集中参数模型更为准确全面地描述了低温贮箱内的流动和热分层现象,并表明有限体积模型体系及所开发的仿真软件具有广泛的适用范围和良好的仿真精度,在管路系统仿真领域具有工程应用价值和数值拓展潜力.
- 航空、航天推进系统 /
- 液体推进剂火箭发动机 /
- 低温贮箱增压系统 /
- 模块化建模 /
- 系统动态仿真
Abstract: Based on the distributed parameter numerical model of cryogenic propellant tank, pressurization of a LO₂ tank pressurization system during engine firing was simulated by employing the liquid rocket engine test-bed modularization modeling and simulation software-gas system(LRETBMMSS-GS).The simulation results agree well with test data and experiential correlation prediction,which shows that the distributed parameter tank model is more accurate and comprehensive than lumped parameter model in describing flow and thermal stratification phenomena in cryogenic tank.Accordingly,the numerical system of finite volume model and corresponding simulation software have a wide applicability and good simulation precision,which are valuable and can be developed further in pipe system simulation field.
- aerospace propulsion system /
- liquid propellant rocket engine /
- cryogenic tank pressurization system /
- modularization modeling /
- system dynamic simulation

HTML

参考文献(9)

[1]	Holt K,Majumdar A.Numerical modeling and test data comparison of propulsion test article helium pressurization system[R].AIAA2000-3719.
[2]	Van Dresar N T.Pressurization of cryogens:a review of current technology and its applicability to low-gravity conditions[R].AIAA92-3061.
[3]	Majumdar A,Steadman T.Numerical modeling oI pressurization of a propellant tank[R].AIAA99-0879.
[4]	张超,鲁雪生,田丽亭.火箭低温液体推进剂增压系统数学模型[J].低温与超导,2005,33(2):35-38.ZHANG Chao,LU Xuesheng,TIAN Liting.The numerical model of rocket cryogenic liquid propellant pressurization system[J].Cryogenics and Superconductivity,2005,32(2):35-38.
[5]	陈阳,张振鹏,瞿骞,等.液体火箭发动机试验台贮箱增压系统数值仿真[J].航空动力学报,2007,22(1):96-101.CHEN Yang,ZHANG Zhenpeng,QU Qian,et al.Numerical simulation for tank pressurization system of LRE testbed[J].Journal of Aerospace Power,2007,22(1):96-101.
[6]	陈阳,高芳,张振鹏,等.低温推进剂贮箱增压系统分布参数数值仿真(Ⅰ)贮箱的有限体积模型[J].航空动力学报,2008,23(2):323-328.CHEN Yang,GAO Fang,ZHANG Zhenpeng,et al.Distributed parameter numerical simulation for the transients of cryogenic propellant tank pressurization system(Ⅰ)Finite volume model of tank[J].Journal of Aerospace Power,2008,23(2):323-328.
[7]	陈阳.液体火箭发动机试验台气路系统通用模块化建模与仿真研究[D].北京:北京航空航天大学,2006.CHEN Yang.Study on generalized modularization modeling and simulation for liquid propellant rocket engine testbed systems[D].Beijing:Beijing University of Aeronautics and Astronautics,2006.
[8]	陈新华主编.运载火箭推进系统[M].北京:国防工业出版社,2002.
[9]	瞿骞.高压、小气枕低温贮箱智能增压技术[J].低温工程,2005,(5):22-25.QU Qian.An intelligence pressurization technology of high pressure and small ullage at low temperature tank[J].Cryogenics,2005,(5):22-25.
