射流襟翼-低压涡轮叶栅主动流动控制数值研究
Numerical study of active flow control using jet-flap for a low-pressure turbine cascade
-
摘要: 针对PAK-B低压涡轮叶型,基于耦合了Langtry-Menter转捩模型的Menter's SSTk-ω两方程模型,数值研究了不同流动状态下射流襟翼的流动控制机理.计算结果表明,射流襟翼能够有效控制PAK-B叶型失速流动状态下的损失,当射流流量百分数为2%,能量损失系数较无射流襟翼控制状态时下降40%;同时,气流转折角增大5%;影响并使主流进口质量流量减小10%,对于叶型未失速流动,控制不一定有效.结果还表明,射流襟翼能够推迟相邻叶型吸力面边界层转捩,从而延迟分离流动再附.Abstract: Based on Menter's SST k-ω turbulence model coupled with Langtry-Menter transition model,the control mechanism of jet-flap,an active flow control method for PAK-Blow-pressure turbine blade profile,was numerically investigated under different flow conditions including different cascade inlet Reynolds numbers,free stream turbulence levels,and cascade outlet Mach numbers.The results show that the jet-flap effectively reduces flow loss when PAK-Bprofile is stalled.With jet flow mass fraction equal to 2%,relative to the baseline,the energy loss coefficient reduced by about 40%;the flow turning angle increased by about 5%;and the inlet primary flow mass reduced by about 10%.When the flow was not stalled,the control could be ineffective.The results also show that the jet-flap delays boundary layer transition on adjacent blade profile suction side, which in turn delays the boundary layer reattachment.
-
Key words:
- aerospace propulsion system /
- jet-flap /
- transition model /
- flow control /
- low-pressure turbine
-
[1] Bons J P,Sondergaard R,Rivir R B.Turbine separation control using pulsed vortex generator Jets[J].ASME J.Turbomach.,2001,123(2):198-206. [2] Sondergaard R,Bons J P,Sucher M,et al.Reducing lowpressure turbine stage blade count using vortex generator jet separation control[R].ASME Paper No.GT-2002-30602,2002. [3] Volino R J.Separation control on low-pressure turbine airfoils using synthetic vortex generator Jets[R].ASME Paper No.GT-2003-38729,2003. [4] Volino R J.Passive flow control on low-pressure turbine airfoils[R].ASME Paper No.GT2003-38728,2003. [5] Lake J P,Rivir R B.Low reynolds number loss reduction on turbine blades with dimples and v-grooves[R].AIAA Paper No.AIAA 2003-0738,2003. [6] Sieverding C H,et.Investigation of the effectiveness of various types of boundary layer transition elements of low reynolds number turbine bladings[R].ASME Paper No.GT2004-54103,2004. [7] Byerley A R.Using guerney flaps to control laminar separation on linear cascade blades[R].ASME Paper No.GT2002-30662,2002. [8] Stanley M N,Jobn F K.Two-dimensional cascade test of a jet-flep turbine rotor blade[R].NASA TM X-2183,1971. [9] Langtry R B,Menter F R.A correlation-based transition model using local cariables Part Ⅱ-Test cases and industry applications[R].ASME Paper No.GT2004-53454,2004. [10] Menter F R,Langtry R B.A correlation-based transition model using local variables Part Ⅰ-Model formulation[R].ASME Paper ASME-GT2004-53452,2004. [11] Huang J,Corke T C,Thomas F O.Plasma actuators for separation control of low pressure turbine blades[R].AIAA Paper No.AIAA-2003-1027,2003. -
