一种定几何混压式二元进气道的再起动特性研究
Investigation of the restart performance of a mixed-compression two-dimensional supersonic inlet with fixed-geometry
-
摘要: 针对一种设计飞行马赫数范围为2.25~4.0的定几何混压式二元超声速进气道由于反压引起的不起动开展了再起动特性风洞实验研究.根据实验结果和二维非定常数值仿真结果分析表明:在Ma=2.51和3.01下进气道性能在进锥/退锥实验中规律一致;按照Ma=2.25的起动面积收缩比确定的喉道面积,使进气道在来流Ma≥2.51时具有自起动能力;而在稳定亚临界状态下具有高的总压恢复系数及形成类似于外压式的气动通道是进气道无回路迟滞现象的主要原因.Abstract: An experimental study was conducted to investigate the restart performance of a fixed-geometry,mixed-compression,two-dimensional supersonic inlet under unstart condition due to raising backpressure,with a designed flight Mach number from 2.25 to 4.0.The test results and two-dimensional unsteady simulation results show that,the inlet performance is consistent in the inlet wall and exit section tests at Mach number of 2.51 and 3.01;the throat area is determined according to the start area shrinkage ratio at Mach=2.25,so that the inlet enables self-start at Ma=2.5 and above.The phenomenon of no hysteresis under stable subcritical condition is because of a high total pressure recovery and a flow pattern of inlet similar to external compression inlet.
-
[1] Seddon J,G ol dsmit h E L.Int ake aerodynam ics[M].London:Blackw ell Science,1999. [2] Van D M,K wok F T,W al sh R F.S tart ing charact erist ics of s upersonic inlet s[R].A IA A 96 2914,1996. [3] Takas ak e S,Brett J C,Fujimot o A,et al.Inlet un st art in fluence on aerodyn ami c charact erist ics of nex t gen erati on s uper sonic t ran sport(SST)[R].A IA A 98-5546,1998. [4] Norm an D W,Warren E A.Ex perim ent al invest igat ional of a larges cale,two dim ens ional,mixed com pres sion inlet s yst em perform ance at super sonic condit ion,M=1.55 to 32[R].N ASA TND 6392,1971. [5] Glenn A M,Robert W C.A n experim ent al invest igat ion of the rest art area rat io of a Mach 30 axisymm et ric mixed com pres sion inlet[R].N A SA TMX 1547,1968. [6] Gary L C,G eorge H N,M ichael J C.An automatic rest artcontrol system for an axi symmet ric mixed com pression inlet[R].N A S A T N D 5590,1969. [7] Bobby W S,Robert W C.Eff ect of bleed syst em back pressure and porous area on the per for mance of an axi symmetric mixed compression inl et at Mach 2 5[R].N A S A TMX 1710,1968. [8] Michael K F,Warren G H,Eli R.Cont rol of shock w ave boundary layer interact ions by bleed in s upersonic mixedcom pression inlet s[R].N A S A CR 2595.1975. [9] Sato T,K aji S.St udy on st eady and unst eady uns tart phenomenadue to com pound chokin g and/or flu ct uation s in com bust or of scramj et engines[R].A IA A 92 5102,1992. [10] H aw kins W R,M arquart E J.Tw o dimen sional generi c in let uns tart det ect ion at M ach 25-50[R].A IA A 95 6019,1995. [11] J osep h F W,Edw ard T M,Paul L B.Experiment al inves tigati on of t h e performance of a Mach 2 7 t w o di mens ional bi fur cat ed du ct inl et with 30 percent in ternal cont ract ion [R].N A SA TM 106728,1996. [12] H errmann C D,K oschel K W.Experimen tal in vest igat ion of the in ternal compr ess ion of a h ypers on ic int ake[R].A IA A 2002 4130,2002. [13] K an t row it z A,Donaldson C.Prel iminary in vest igati on of super sonic diff ers[R].N A C A W RL 713,1945. [14] Rudolf H.Sup ersoni c inlet dif fus ers an d int roduct ion to int ernal aerodynam ics[R].M inneapoli s:M inneapoli cs H oneyw ell R egult or Company,1953. [15] 谢旅荣,郭荣伟.定几何混压式轴对称超声速进气道气动特性数值仿真和实验验证[J].航空学报,2007,28(1):78-83.X IE L rong,GUO R on gw ei.N umerical simul at ion and experiment al validat ion of the flow in a m ixed compr ess ionaxisym metric super sonic inlet with f ixed geom et ry[J].Act a A eronau ticaet A stronaut ica S inica,2007,28(1):78-83.
