模拟刷式封严泄漏流动的多孔介质模型

A porous medium model for simulating leakage flows through brush seals

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要: 将刷束处理为多孔介质,在动量方程中引入由于多孔介质对流体流动的阻碍作用而引起的动量源项,之后详细分析了刷束孔隙率的确定方法并根据实验结果确定了该孔隙率,从而建立了模拟刷式封严泄漏流动的多孔介质模型.对该模型的计算结果做进一步的修正后,可以与实验结果很好地吻合,证明了利用该模型预测刷式封严的泄漏量是可行的.
- 航空、航天推进系统 /
- 刷式封严 /
- 泄漏流动 /
- 多孔介质 /
- 数值模型
Abstract: The bristle pack was treated as porous medium.Amomentum source term which was caused by the porous medium was added into the momentum equation.The method to determine porosity of the pack was examined in detail and the porosity was obtained based on the experimental results.So a porous medium model for simulating the leakage through brush seals was built up.The computational results,after correction,show a good agreement with the experimental results.The model was proved to be practicable for predicting the leakage of brush seals.
- aerospace propulsion system /
- brush seal /
- leakage /
- porous medium /
- numerical model

[1]	Chupp R E,Holle G F.Generalizing circular brush seal leakage through a randomly distributed bristle bed[J].Journal of Turbomachinery,1996,118:153-161.
[2]	Chew J W,Hogg S I.Porosity modeling of brush seals[J].ASME Journal of Tribology,1997,119:769-775.
[3]	丁水汀,陶智,徐国强.刷式封严流动和换热的数值模拟[J].推进技术,1999,20(1):65-67.DING Shuiting,TAO Zhi,XU Guoqiang.Numerical simulation on fluid flow and heat transfer of a brush seal configuration[J].Journal of Propulsion Technology,1999,20(1):65-67.
[4]	黄学民,史伟,王洪铭.刷式密封中泄漏流动的多孔介质数值模型[J].航空动力学报,2000,15(1):55-58.HUANG Xuemin,SHI Wei,WANG Hongming.Porous medium leakage flow model of brush seal[J].Journal of Aerospace Power,2000,15(1):55-58.
[5]	王之栎,王宗根,孙丽霞.刷密封内流动与密封特性的研究[J].润滑与密封,2005(6):114-116.WANG ghili,WANG Zonggen,SUN Lixia.Research on flow and seal character in brush seal[J].Lubrication Engineering,2005 (6):114-116.
[6]	谢晓俊,康宁.低泄漏高寿命刷式封严的数值计算[J].航空动力学报,2003,18(6):824-826.XIE Xiaojun,KANG Ning.Numerical computation of low leakage and high endurance brush seal[J].Journal of Aerospace Power,2003,18(6):824-826.
[7]	Short J F,Basu P,Data A,et al.Advanced brush seal development[R].AIAA Paper 96-2907.
[8]	FLUENT User's Guidel[Z].Fluent Inc.,2003.
[9]	林瑞泰.多孔介质传热传质引论[M].北京:科学出版社,1995.
