静态封严篦齿内部流动与换热的数值计算

刘振侠; 赵海刚; 张丽芬; 吴丁毅; 王小峰

静态封严篦齿内部流动与换热的数值计算

1.
西北工业大学动力与能源学院, 西安 710072
2.
中国飞行试验研究院, 西安 710089

计量
- 文章访问数: 1856
- HTML浏览量: 1
- PDF量: 408
- 被引次数: 0
出版历程
- 收稿日期: 2007-03-27
- 修回日期: 2007-06-25
- 刊出日期: 2008-03-28

Numerical analyses of flow field and heat transfer in cavity of straight labyrinth seal at static state

1.
School of Power and Energy, Northwestern Polytechnical University Xi'an 710072, China
2.
Chinese Flight Test Establishment Xi'an 710089, China

摘要

摘要: 建立二维篦齿模型,运用数值方法,从分析齿腔内流场和篦齿顶板换热的角度研究了篦齿的封严特性.通过多种工况的计算,探讨了雷诺数、齿顶宽和齿隙之比对篦齿腔内流动、压降损失以及齿腔顶板换热系数之间的关系.计算数据和实验数据进行比较,发现变化规律一致,误差较小.研究结果表明:雷诺数、齿顶宽和齿隙之比影响着齿腔内部流动和换热的状态,是最终成为决定篦齿封严效果的重要因素.
- 航空、航天推进系统 /
- 直通式封严篦齿 /
- 雷诺数 /
- 换热系数
Abstract: In order to investigate the performance of straight sealing labyrinth at static state in aero engine,a model of straight sealing labyrinth was established and applied to compute the flow characteristics and heat transfer in the straight sealing labyrinth.With the result of numerical simulation,the effects of Reynolds numbers and T/Con flow field,pressure loss,and coefficient of heat transfer were studied.By comparing some group results of numerical simulation and experiments data,it is found that the numerical results are in agreement with experimental data and the error can be acceptable.The results show that the Reynolds number and T/Caffect the flow characteristics and heat transfer in the straight sealing labyrinth and thus are important factors in deciding the sealing performance of straight labyrinth.
- aerospace propulsion system /
- straight sealing labyrinth /
- Reynolds number /
- heat transfer coefficient

HTML

参考文献(5)

[1]	黄晓光.封严篦齿内部流动与换热的试验研究[D].西安:西北工业大学,1997.HUANG Xiaoguang.The investigation of flow field and heat transfer in cavity of labyrinth sealED].Xi'an:North-western Polytechnical University,1997.
[2]	尚显峰.封严篦齿内流动和换热的实验研究和数据模拟[D].西安:西北工业大学,1998.SHANG Xianfeng.The numerical analyses and experimental investigations of flow field and heat transfer in cavity oflabyrinth seal[D].Xi' an:Northwestern Polytechnical University,1998.
[3]	Yucel U,Kazakia J Y.Analytical prediction tech-niques for axisymmetric flow in gas labyrinth seals[J].Journal of Engineering for Gas Turbines and Power,2001,123:255-257.
[4]	Willenborg K.Effects of Reyonlds number and pressure ratio on leakage loss and heat transfer in a stepped labyrinth seal[J].Journal of Turban Achinery,2001,123:815-822.
[5]	王锁芳,吕海峰.转静态封严篦齿流场的数值分析和封严特性的实验研究[J].航空动力学报,2005,20(3);444-449.WANG Suofang,LU Haifeng.Numerical analysis of flow and experimental investigation of labyrinth sealing characteristics at rotational and static states[J].Journal of Aerospace Power,2005,20(3):444-449.
