静叶吸气对某轴流压气机裕度影响的研究
Research of influence of stator blade suction on the stall margin of axial compressor
-
摘要: 运用Numeca CFD对某大弯度叶栅和某轴流压气机流动进行数值模拟,为减小由于边界层分离而带来的损失,拓宽稳定工作范围,提出叶片吸力面表面开缝抽气方案.综合研究开缝位置、开缝长度、及吸气量大小对流动分离结构和裕度的影响.结果表明通过静子叶片上边界层抽气引出分离区域的低能量气流,可以明显的改善气动性能,分离得到很好的抑制,稳定工作裕度得到了提高.Abstract: Numeca CFDcommercial software was used to simulate numerically the flow field of a high-turning cascade and axial compressor.In order to mitigate the loss from boundary layer separation and expand the working range,a proposal for slot suction on blade suction surface was presented.The influences of position of slots,length of slots and the mass flow of suction on the separation structure and stall margin were investigated.The results show that,the aerodynamic performance could be improved significantly through release of low-energy air current at upstream boundary layer of stator blade,and the flow separation could also be postponed with improved stall margin.
-
[1] Carter C J.Aerodynamic performance of a high-turning compressor stator with flow control[C]//AIAA-2001-3973 37thAIAA/ASME/SAE/ASEE Joint Propulsion-Conferneee & Exhibit Conference.SaltLake City:Utah July 2001. [2] 王松涛,潜纪儡,冯国泰,等.壁面吸气抑制分离减少流动损失的研究[C]//中国工程热物理学会2004年学术会议.西安:中国工程热物理学会,2004. [3] Schuler B J.Kerrebrock J L,Merchant A A,et al.Design,analysis,fabrication and test of an aspirated fan stage[R].International Gas Turbine & Aeroengine Congress & Exhibition Munich,Germany-May 8-11,2000. [4] Rao N M,Feng Jinwei,Burdisso R A.Active flow control to reduce fan blade vibration and noise[R].AIAA-99-1806,1999 American Institute of Aeronautics & Axtronautics [5] Bailie S T,Burdisso R A,Ng W F.Wake filling and reduction of rotor HCF using stator trailing edge blowing[R].AIAA-2000-3101,38thAIAA/ASME/SAE/ASEE Joint PropulsionConfernece & Exhibit Conference.Huntsville,AL:July 2000. [6] Vandeputte T W.Effects of flow control on the aerodynamics of a tandem inlet guide vane[D].MS Thesis,Virginia Polytechnic Institute and StateUniversity,Blacksburg,VA:January,2000. [7] Steinert W,Eisenberg B.Design and testing of a controlled diffusion airfoil cascade for industrial axial flow compressor application[J].Trans.of ASME(A),J.of Turbomachinery,1991,113:583-590. [8] 周海.李秋实.陆亚钧.跨声风扇转子叶片抽吸气数值实验探索[J].航空动力学报,2004,19(3):409-412ZHOU Hai,LI Qiushi,LU Yajun.Prospects of numerical analysis of an aspirated transonic fan rotor[J].Journal of Aerospace Power,2004,19 (3):409-412. [9] 邓睥,顾春伟.压气机级间抽气的数值模拟[C]//中国工程热物理学会2006年学术会议.重庆;中国工程热物理学会,2006.
