单向带/平纹布混杂铺层层合板极限强度研究
Investigation on the ultimate strength of unidirectional tapes and plain cloth hybrid laminates
-
摘要: 单向带/平纹布混杂铺层方式常用于复杂复合材料结构的制备,对其极限强度进行研究具有重要的工程应用价值.把三维有限元方法和优化设计思想结合起来,建立了一种复合材料极限强度分析方法,该方法可基于通用有限元分析软件ANSYS实现.为验证该方法的有效性,实验制备了单向带/平纹布混杂铺层层合板进行了拉伸和压缩实验.结果表明该方法用于混杂铺层层合板极限强度预测,最大偏差在15%以内,满足工程应用要求.Abstract: Unidirectional-tapes/plain-cloth hybrid laminates are widely applied in fabricating complex composite structures.Atheoretical analysis approach was established in the present paper to predict the ultimate strength of the tapes/plain-cloth reinforced composites based on three dimensional finite element analysis and optimum design method.The tension and compression experiments on the tapes/plain-cloth laminates were done to verify the effectiveness of the theoretical method put forward in this paper.The deviation of the ultimate strength between the theoretically predicted results and the experimental results are within15%.
-
Key words:
- aerospace propulsion system /
- plain cloth /
- unidirectional tape /
- composite /
- hybrid lamination /
- ultimate strength /
- finite element
-
[1] 蒋邦海,张若棋.一种碳纤维织物增强复合材料的层间冲击拉伸力学性能实验研究[J].复合材料学报,2005,22(5):107-112.JIANG Banghai,ZHANG Ruoqi.Experimental study onthe interlaminar tensile properties for a kind of carbon fiber woven reinforced composite under impact loading[J].Acta Materiae Compositae Sinica,2005,22(5),107-112. [2] Saunders R A,Lekakou C,Bader M G.Compression and microstructure of fibre plain woven cloths in the processing of polymer composites[J].Composites Part A,1998,29A:443-454. [3] European Space Research and Technology Centre.Composites design handbook for space structure application[M].Holland,ESA Publication Division,1988. [4] Hinton M J,Kaddour A S,Soden P D.A further assessries for composite laminates:comparison with experimental evidence[J].Composites Science and Technology,2004,64:549-588. [5] Hinton M J,Kaddour A S,Soden P D.A comparison of the predictive capabilities of current failure theories for composite laminates judged against experimental evidence[J].Composites Science and Technology,2002,62:1711-1724. [6] HUANG Zhengming.A bridging model prediction of the ultimate strength of composite laminates subjected to biaxial loads[J].Composites Science and Technology,2004,64:395-448. [7] Kolakowski Z.On some aspects of the modified Tsai-Wu criterion in thin-walled composite structures[J].Thinwalled Structures,2003,41:357-374. [8] Tsai S W,Hahn H T.Introduction to composite materials[M].Westport,CT,USA,Technomic Publishing Co.,Inc.,1980:280. [9] Liu K S,Tsai S W.A progressive quadratic failure criterion for a laminate[J].Composites Science and Technology,1998,58:1023-1032. [10] 王向阳,陈建桥.基于最终失效强度的层合板结构的鲁棒优化分析[J].机械强度,2004,(6):675-679.WANG Xiangyang,CHEN Jianqiao.Robust design of laminated composite plates based on the last-ply failure criterion[J].Journal of Mechanical Strength,2004,26 (6):675-679. [11] 王兴业.复合材料力学分析与设计[M].长沙:国防科技大学出版社,1999.
