RBCC火箭引射模态热力壅塞研究

吕翔; 何国强; 刘佩进; 李宇飞

RBCC火箭引射模态热力壅塞研究

西北工业大学航天学院, 西安 710072

基金项目: 国家863计划项目

计量
- 文章访问数: 1595
- HTML浏览量: 2
- PDF量: 504
- 被引次数: 0
出版历程
- 收稿日期: 2007-02-06
- 修回日期: 2007-09-17
- 刊出日期: 2008-03-28

An investigation of thermal choke in rocket ejector mode

School of Astronautics, Northwestern Polytechnical University, Xi'an 710072, China

摘要

摘要: 运用理论分析和实验研究相结合的方法对火箭引射模态下实现热力壅塞进行了研究.建立了用于实现热力壅塞可行性分析的理论模型,分析了燃烧室通道面积变化规律、加热方案、一次火箭与二次流掺混后的气流参数等对实现热力壅塞的影响,提出了判别能否实现热力壅塞的临界马赫数准则.理论计算和实验研究结果表明,碳氢燃料发动机在地面静止状态下难以实现热力壅塞,在一定飞行状态下可以实现热力壅塞.通过地面直连实验实现了来流马赫数为1.2条件下的热力壅塞及其主动控制,壅塞位置的调节范围达到了燃烧室长度的1/4.
- 航空、航天推进系统 /
- 火箭基组合循环 /
- 火箭引射模态 /
- 热力壅塞
Abstract: Thermal choke active control in rocket ejector mode and ramjet mode was investigated theoretically and experimentally for the integral design of RBCCengine.Theoretic model for possibility analysis of realizing thermal choke was set up.The effect of combustor geometry,heat adding scheme,flow parameters of the primary and secondary mixture on thermal choke was analyzed.Aprinciple of critical Mach number for determining the possibility of reaching thermal choke was proposed.Both theoretical results and experimental results show that it's difficult to reach thermal choke at sea level static for HC-fueled RBCCengine,while it becomes more easily under some flight conditions.Thermal choke with active control was achieved under the flight Mach number 1.2 on the direct-connecting test facilities of NWPU,with the adjustable range up to one quarter of the combustor length.
- aerospace propulsion system /
- rocket based combined cycle(RBCC) /
- rocket ejector mode /
- thermal choke

HTML

参考文献(9)

[1]	李字飞,何国强,刘佩进.热力喉道调节工作原理分析[J].弹箭与制导学报,2005,25(4):376-378.LI Yufei,HE Guoqiang,LIU Peijin.Theory analysis of thermal throat adjustment[J].Journal of Projectiles,Rockets,Missiles and Guidance,2005,25(4):376-378.
[2]	Quinn J E.ISTAR:Project status and ground test engine design[R].AIAA Paper 2003-5235.
[3]	Bond R B,Edwards J R.CFD analysis of the low speed propulsion mode in an RBCC engine[R].AIAA Paper 2004-857.
[4]	刘佩进,何国强,李宇飞.RBCC引射火箭模态二次燃烧实验[J].推进技术,2004,25(1):75-77.LIU Peijin,HE Guoqiang,LI Yufei.Effect of secondary combustion in rocket ejector[J].Journal of Propulsion Technology,2004,25(1):75-77.
[5]	[美]左克罗M.J,霍夫曼J.D.气体动力学[M].王汝勇,译.北京:国防工业出版社,1984.
[6]	吕翔.RBCC发动机性能分析方法研究[D].西安:西北工业大学研究生院,2005.LU Xiang.Study on performance analysis model of rocketbased-combined-cycle (RBCC) engine[D].Xi 'an:Master Thesis of Northwestern Polytechnieal University,2005.3.
[7]	李宇飞,何国强,刘佩进.SMC燃烧模式下引射火箭性能影响因素的实验研究[J].推进技术,2006,27(2):97-100.LI Yufei,HE Guoqiang,LIU Peijin.Experimental study for factors affecting rocket ejector performance in SMC combustion mode[J].Journal of Propulsion Technology,2006,27(2):97-100.
[8]	吕翔,何国强,刘佩进.RBCC引射模态准一维性能分析模型[J].推进技术,2006,27(6):529-531.LU Xiang,HE Guoqiang,LIU Peijin.Quasi-lD analysis model of rocket ejector mode[J].Journal of Propulsion Technology,2006,27(6):529-531.
[9]	黄生洪,何洪庆,何国强,等.构型及二次燃烧对RBCC引射模态推力性能的影响[J].空气动力学学报,2005,23(2):139-143.HUANG Shenghong,HE Hongqing,HE Guoqiang,et al.Effects of configuration and secondary combustion on RBCC thrust in ejecting mode[J].Acta Aerodynamica Sinica,2005,23(2):139-143.
