斜齿面齿轮齿宽的设计

基金项目: 国家自然科学基金项目(50675176)

The design of tooth face width of the face-gear drives with helical pinion

School of Mechanical and Electronic Engineering, Northwest Polytechnical Unversity, Xi'an 710072

摘要: 研究了斜齿面齿轮小端不根切和大端不变尖的问题.给出了任意轴交角条件下小端不产生根切的内半径和大端不变尖的外半径的表达式.提出了在产形齿轮上求解关键点的方法.定义了内半径系数,外半径系数和齿宽系数三个无量纲量,分析表明产形轮齿面螺旋角和小齿轮齿数的大小决定了三个系数的变化趋势.
- 机械传动 /
- 斜齿轮 /
- 面齿轮 /
- 齿轮齿宽
Abstract: A voidance of undercutting or pointing in the toe and heel of the face-gear drives with helical pinion was mainly discussed in the paper.The expressions of inner radius and outer radius able to prevent undercutting or pointing under arbitrary shaft angle that formed by shaper and face-gear were also presented.Anew method was developed for solution of critical point of undercutting on the shaper tooth surface.Three unitless coefficients of inner radius,outside radius and tooth width were defined.The results show that these three coefficients depend on the magnitude of helix angle of the shaper and the number of teeth of spur helical pinion.
- mechanical transmission /
- helical gear /
- face-gear /
- tooth face width

[1]	Lewicki D G,Handschuh R F,Heath G F,et al.Evaluation of carburized and ground face gears[R].NASA/TM-1999-209188,ARL-TR-1998.
[2]	Heath G F,Bossier R B.Advanced rotorcraft transmission (ART) program-final report[R].NASA CR-191057,Army Research Laboratory ARL-CR-14,January 1993.
[3]	Filler R R,Heath G F,Slaughter S C,et al.Torque splitting by a concentric face gear transmission[R].The American Helicopter Society 58th Annual Forum,Montreal,Canada:June 11-22,2002.
[4]	Litvin F L.Gear geometry and applied theory[M].Englewood Cliffs,NJ:Prentice Hall,Inc.,1994.
[5]	朱如鹏,高德平.在面齿轮设计中避免根切和齿顶变尖的设计方法的研究[J].中国机械工程,1999,10(11):1274-1276.ZHU Rupeng,GAO Deping.Study on the method of avoiding dedendum undercuttin and addendum pointing in face gear design[J].China Mechanical Engineering,1999,10(11):1274-1276.
