基于替代模型的高超声速前体/进气道一体化优化
An integrated optimization of hypersonic forebody/inlet based on surrogate models
-
摘要: 采用基于替代模型的渐进优化策略对二维高超声速前体/进气道进行一体化设计优化,采用拉丁超立方试验设计法选择样本点,采用二维粘性CFD方法计算进气道流场来建立样本数据库,综合运用了多项式响应面、Kriging模型、BP神经网络和径向基神经网络等替代模型.相对于基准构型,前体/进气道的优化构型在设计态时提高了流量捕获与来流压缩能力,提高了总压恢复性能,同时减小了阻力系数,综合性能提高了5.3%;在非设计态时优化构型的综合性能也有不同程度的改善.Abstract: Asuccessive optimization strategy based on surrogate models was applied to integrated optimization of a hypersonic 2Dforebody/inlet.The sample data points were selected by Latin Hypercubes design of experiment technique,and the sample database was constructed by forebody/inlet flowfield numerical calculation using computational fluid dynamics(CFD) method based on2Dviscous Navier-Stokes equation.Four types of surrogate models including polynomial response surface,Kriging model,BPneural network and radial bases function neural network were adopted.As compared with baseline forebody/inlet at on-design state,the optimal forebody/inlet has better flow capture and compression and total pressure recover capability,and has lower drag force coefficient,with 5.3% improvement of overall performance.The performance of optimal forebody/inlet at off-design states has also improved to some extent.
-
[1] 徐旭,蔡国飙.超燃冲压发动机二维进气道优化设计方法研究[J].推进技术,2001,22(6):468-472.XU Xu,CAI Guobiao.Design and optimization method for two dimensional scramjet inlet[J].Journal of Propulsion Technology,2001,22(6):468-472. [2] 罗世彬,罗文彩,丁猛,等.超燃冲压发动机二维进气道多级多且标优化设计方法研究[J].国防科技大学学报,2004,26(3):1-6.LUO Shibin,LUO Wencai,DING Meng,et al.The study of multi-level and multiobjective optimization design method for two dimensional scramjet inlet[J].Journal of National University of Defense Technology,2004,26(3):1-6. [3] 王振国,陈小前,罗文彩,等.飞行器多学科设计优化理论与应用研究[M].北京:国防工业出版社,2006.WANG Zhenguo,CHEN Xiaoqian,LUO Wencai,et al.Research on the theory and qpplication of multi-disciplinary design optimization of flight vehicles[M].Beijing:National Defence Industry Press,2000. [4] Lin Y,Mistree F,Allen J K.Sequential metamodeling in engineering design[R].AIAA 2004-4304,2004. [5] 陈立周.稳健设计[M].北京:机械工业出版社,1999. [6] Cressie N A C.Statistics for spatial data[M].New York:John Wiley & Sons,1993. [7] 阎平凡,张长水.人工神经网络与模拟进化计算[M].北京:清华大学出版社,2000. [8] iSIGHT Reference guide(Version 8.0)[M].Engineous Software,Inc,2002. [9] Wie D M V,Ault D A.Internal flowfield characteris-tics of a scramjet Inlet at mach 10[J].Journal of Propulsion and Power,1996.12(1):158-164 -
