尾缘吹气稳定器缝宽对燃烧性能影响的试验

杨阳; 马文杰; 樊未军; 岳明; 杨茂林

尾缘吹气稳定器缝宽对燃烧性能影响的试验

北京航空航天大学能源与动力工程学院, 北京 100083

计量
- 文章访问数: 1912
- HTML浏览量: 237
- PDF量: 433
- 被引次数: 0
出版历程
- 收稿日期: 2007-04-30
- 修回日期: 2008-03-20
- 刊出日期: 2008-05-28

Experimental on the effects of jet exit width on EBMC flameholders' combustion performance

School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 为了探讨尾缘射流出口缝宽对燃烧性能的影响,在来流λ_m-0.1,0.18,0.25和丁T_m-53,63,3 K状态条件下,分别对缝宽为1,2,4 mm的尾缘吹气式稳定器和V型稳定器的燃烧性能进行了试验研究,对比分析了它们的贫熄特性、温度分布和燃烧效率.燃烧试验结果表明缝宽对尾缘吹气式稳定器燃烧性能有明显影响.在本模拟条件下,缝宽较窄的稳定器贫熄边界较宽,缝宽为1 mm的尾缘吹气式稳定器贫熄边界最宽;从出口温度分布可以看出,缝宽小的尾缘吹气式稳定器高温区域较大;缝宽较小的稳定器燃烧效率较高,缝宽1 mm的稳定器燃烧效率最高.
- 航空、航天推进系统 /
- 火焰稳定器 /
- 气动稳定 /
- 加力燃烧
Abstract: To study the effects of jet exit width on the combustion performance,the combustion performance of edge blowing mixture curtain flameholders(EBMC) and a V gutter with 1mm,2mm or 4mm jet exit width was investigated experimentally under λ_m =0.1,0.18,0.25 and T_m=573 K,673 K,773 K condition,and the lean limit of the flame stabilization,temperature distribution and combustion efficiency of flameholders were compared and analyzed.The results of combustion experiments show that jet exit width affect EBMC flameholders combustion performance evidently.Under the simulation condition,the lean limit of the flame stabilization is wider when jet exit width is narrower,so lean limit of the flame stabilization of 1mm jet exit width EBMC is widest.The temperature distribution of flameholders shows that high temperature area of narrow jet exit EBMC flameholders is bigger.And combustion efficiency is higher when flameholders jet exit width is narrower,so combustion efficiency of 1mm jet exit width EBMC is highest.
- aerospace propulsion system /
- flame holder /
- aerodynamic stabilization /
- afterburning

HTML

参考文献(9)

[1]	王家骅.蒸发式火焰稳定器的稳定机理研究[J].南京航空航天大学学报,1980,12(01):69-84.WANG Jiahua.A mechanism of flame stabilization by means of vapour gutter in pre-mixed flow[J].Journal of Nanjing University of Aeronautics & Astronautics,1980,12(01):69-84.
[2]	宁晃,高歌.沙丘驻涡火焰稳定性的理论及实验研究[J].工程热物理学报,1982,3(01):89-95.NING Huang,GAO Ge.Theoretical and experimental study in stability of the barchan dune vortex flame[J].Journal of Engineering Thermophysics,1982,3(01):89-95.
[3]	张洪滨,王纪根.双V型火焰稳定器的研制和应用[J].推进技术1994,6(3):38-43.ZHANG Hongbin,WANG Jigen.Development and application of double v type flame stabilizer[J].Journal of Propulsion Technology,1994,6(3):38-43.
[4]	Sridhara K,Chidananda M S,Paranjpe P A.Jet curtain flameholder for aircraft afterbumers[R].78-GT-95.
[5]	Peck R E,Samuelsen G S.Generalized stability criteria for an opposed-jet flameholder[R].AIAA 82-4229.
[6]	Sridhara K,Chidananda M S.Fresh mixture entertainment in a jet curtain flameholder[R].Fifth International Symposium on Airbreathing Engines,February 1981.
[7]	杨茂林,全中.尾缘吹气式火焰稳定器试验研究[J].航空动力学报,1998,13(2):185-188.YANG Maolin,QUAN Zhong.Experimental investigation on EBMC flameholder[J].Journal of Aerospace Power,1988,13(2):185-188.
[8]	岳连捷,杨茂林.尾缘吹气式火焰稳定器燃烧性能研究[J].航空动力学报,2001,16(4):345-349.YUE Lianjie,YANG Maolin.Research on combustion performance of the edge blowing mixture curtain flameholder[J].Journal of Aerospace Power,2001,16(4):345-349.
[9]	岳连捷,杨茂林.火焰稳定器射流喷口形状对燃烧性能的影响[J].推进技术,2003,24(2):169-171.YUE Lianjie,YANG Maolin.Influence of jet slot structure on combustion performance of novel jet flameholder[J].Journal of Propulsion Technology,2003,24(2):169-171.
