超声速气膜冷却数值模拟

王建; 孙冰; 魏玉坤

超声速气膜冷却数值模拟

1.
北京航空航天大学宇航学院, 北京 100083
2.
中国人民解放军空军第四飞行学院模拟训练中心, 石家庄 050071

计量
- 文章访问数: 2163
- HTML浏览量: 535
- PDF量: 488
- 被引次数: 0
出版历程
- 收稿日期: 2007-05-08
- 修回日期: 2007-10-22
- 刊出日期: 2008-05-28

Numerical simulation of supersonic gaseous film cooling

1.
School of Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100083, China
2.
Simulator Training Center of NO.4 Flying College of the Air Force of PLA, Shijiazhuang 050071, China

摘要

摘要: 应用SST k^-ω湍流模型,对三维粘性掺混流场进行了数值模拟,得到了切向入射的超声速气膜在不同吹风比和冷却通道下的绝热温比分布.计算结果表明:吹风比是决定超声速气膜冷却效果的重要因素,吹风比增大,冷却效果随之提高;冷却通道不同,冷却效率的分布规律也不同,矩形孔在出口处存在冷却效果较低的区域;离散孔冷却通道在下游和冷却通道中间线上的冷却效果存在明显差异,侧向倾角的引入使这种差异消失;扩散孔和侧向倾角两种结构上游冷却效果好,但下游衰减更快;引入的评价参数可以为比较不同的气膜冷却方式提供参考.
- 航空、航天推进系统 /
- 超声速 /
- 气膜冷却 /
- 数值模拟 /
- 绝热温比
Abstract: The SSTk^-ω turbulence model was employed to simulate numerically 3Dviscous mixing flow field in order to investigate the supersonic gaseous film cooling injected from different cooling channels tangentially.Results show that blowing rate is an important factor,the adiabatic film cooling effectiveness is enhanced with the increase of the blowing rate.Through different cooling channels,the film cooling has different distribution rules,the cuboids channel is the worst one.The film cooling effectiveness is different between2 kinds of centerlines in the discrete coolant channels,which can be avoided by the β angle.The distribution of adiabatic film cooling effectiveness on the wall indicates that the outspread hole and column with β are better in the foreside,but decline more quickly.3 valuable parameters are introduced to evaluate the supersonic film cooling.
- aerospace propulsion system /
- supersonic /
- gaseous film cooling /
- numerical simulation /
- adiabatic film cooling effectiveness

HTML

参考文献(6)

[1]	Aupoix B,Mignosi A,Viala S.Experimental and numerical study of supersonic film cooling[J].AIAA J,1998,36(6):916-923.
[2]	韩启祥,何小明,谈浩元,等.超声速射流气膜冷却效果的试验研究[J].南京航空航天大学学报,1998,30(5),491-495.HAN Qixiang,HE Xiaoming,TAN Haoyuan,et al.Experimental investigation of supersonic gaseous film cooling effectiveness[J].Journal of Nanjing University of Aeronautics & Astronautic,1998,30(5):491-495.
[3]	朱惠人,许都纯,刘松龄.气膜孔形状对排孔下游冷却效率的影响[J].航空学报,2002,23(1):75-78.ZHU Huiren,XU Duchun,LIU Songling.Effects of hole shape on film cooling effectiveness[J].Acta Aeronautica Et Astronautica Sinica,2002,23(1):75-78.
[4]	YANG Xiaobo,Badcockt K J,Richards B E,et al.A numerical study of hypersonic turbulent film cooling[C]//43rd AIAA Aerospace Sciences Meeting and Exhibit.Reno,Nevada:2005,AIAA 2005-386.
[5]	刘江涛,吴海玲,陶涛,等.斜孔气膜冷却数值模拟分析[J].工程热物理学报,2004,25(6):1034-1036.LIU Jiangtao,WU Hailing,TAO Tao,et al.Numerical simulation of film cooling[J].Journal of Engineering Thermophysics,2004,25(6):1034-1036.
[6]	原和朋,朱惠人,孔满昭.后台阶三维缝隙冷却效率的数值模拟[J].燃气轮机技术,2006,19(4):38-42.YUAN Hepeng,ZHU Huiren,KONG Manzhao.Numeri-cal investigation of back-step three dimensional slots on film cooling effectiveness[J].Gas Turbine Techology,2006,19(4):38-42.
