油气匹配及后体进气量对TVC燃烧性能的影响

基金项目: 航空科学基金资助项目(2006ZB51021)

Effect of different fuel-air matching forms on combustion performance of trapped vortex combustor

National Key Laboratory on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要: 针对一种以煤油为燃料的驻涡燃烧室（TVC）,在前期研究的基础上对其前体油气匹配进行几种结构改进,并在试验中重点进行油气匹配和后体进气量的改变对燃烧室燃烧性能的影响.针对其应用于涡轮前及涡轮间二级燃烧的前景,试验中驻涡燃烧室仅采用凹腔供油.试验结果表明,采用改进后供油蒸发管的燃烧效率比改进前提高了12%;在试验条件下,当凹腔当量比小于1.5时燃烧效率达到95%以上.各个方案在不同工况下,出口热点温度分布系数f在0.05⁰.015之间.
- 航空、航天推进系统 /
- 驻涡燃烧室 /
- 油气匹配 /
- 燃烧效率
Abstract: To investigate the combustion efficiency and temperature distribution performance of a trapped vortex combustor(TVC)test rig,many experiments were conducted for structural improvement of fuel-air matching under various inlet conditions. Concavity oil supply was applied to TVCduring the experiment in view of the secondary combustion in front of and between turbines.The results of the experiment indicate that,the combustion efficiency could increase by 12%;when the concavity equivalence ratio is less than1.5,the combustion efficiency will reach over 95%;Pattern factor(f) of all the cases is between0.05 and 0.015 in various working conditions.
- aerospace propulsion system /
- TVC /
- fuel-air matching /
- combustion efficiency

[1]	Hsu K Y,Goss L P.Characteristics of a trapped-vortex comhustor[J].Journal of Propulsion and Power,1998,14(1):57-65.
[2]	Burrus D L,Johnson A W,Roquemore W M.et al.Performance assessment of prototype trapped vortex combustor concept for gas turbine application[R].ASME 2001-GT-0087.
[3]	Roquemore W M,Shouse D,Burrus D,et al.Trapped vortex combustor concept for gas turbine engines[R].AIAA 2001-0483.
[4]	樊未军,易琪,严明,等.驻涡燃烧室凹腔双涡结构研究[J].中国电机工程学报,2006,26(9):66-70.FAN Weijun,YI Qi,YAN Minx,et al.A study of double vortex structure in the trapped vortex combustor[J].Proceedings of the CSEE,2006,26(9):66-70.
[5]	Meyer T R,Brown M S,Fonov S,et al.Optical diagnostics and numerical characterization of a trapped-vortex combustor[R].AIAA 2002-3863.
[6]	Hendficks RC,ShouseDT,Roquemore W M.Water injected turbo machinery[R].NASA/TM-2005-212632.
