导弹尾部外形对发动机水下点火推力的影响

张有为; 王晓宏

导弹尾部外形对发动机水下点火推力的影响

中国科学技术大学热科学和能源工程系, 合肥 230026

基金项目: 教育部新世纪优秀人才支持计划

计量
- 文章访问数: 1514
- HTML浏览量: 73
- PDF量: 455
- 被引次数: 0
出版历程
- 收稿日期: 2007-05-11
- 修回日期: 2007-10-16
- 刊出日期: 2008-05-28

Influence of outline of missile tail on the thrust of solid motor launching under water

Department of Thermal Science and Energy Engineering, University of Science and Technology of China, Hefei 230026, China

摘要

摘要: 利用球形气泡模型,通过数值求解研究了导弹尾部对发动机水下点火时推力峰值、尾部压力分布以及推力波动特性的影响.计算结果表明:尾部收敛段半锥顶角的变化对推力峰值影响较大,半锥顶角大于45°时,随着半锥顶角的减小,推力峰值缓慢下降;半锥顶角小于45°时,推力峰值随着半锥顶角的减小而加速下降;半锥顶角对推力达到峰值的时间影响较小;推力达到峰值时尾部收敛段压力分布变化较大;半锥顶角对推力波动特性影响很小.
- 航空、航天推进系统 /
- 火箭发动机 /
- 水下点火 /
- 尾部外形
Abstract: By using the sphere model,the influences of outline of missile tail upon the thrust peak,pressure distribution on the tail and the oscillation character of the thrust for solid motor launching under water are numerically studied.Results indicate that the half-cone-angle of convergent segment has great effect upon thrust peak.The thrust peak decreases slowly as the half-cone-angle is above 45 degree,and decreases quickly as the half-cone-angle is less than45 degree.But the half-cone-angle has very little effect upon the time for thrust reaching the peak.It is also shown that the pressure distribution varies a lot on the convergent segment of the missile tail as thrust reaches the peak value.The half-cone-angle has little effect on the oscillation frequency of thrust.
- aerospace propulsion system /
- solid motor /
- launching under water /
- outline of tail

HTML

参考文献(13)

[1]	王宝寿,许晟,易淑群,等.水下推力矢量特性试验研究[J].船舶力学,2000,4(5):9-15.WANG Baoshou,XU Sheng,YI Shuqun,et al.Test studies of underwater thrust vector control performance[J].Journal of Ship Mechanics,2000,4(5):9-15.
[2]	王聪,王学孝,徐世昌,等.潜射导弹运动特性的分析与测试[J].导弹与航天运载技术,2002(2):1-4.WANG Cong,WANG Xuexiao,XU Shichang,et al.Analysis and testing on dynamic property of submarine-lanunched missle[J].Missiles and Space Vechicles,2002(2):1-4.
[3]	鲁传敬,陈方,樊泓,等.导弹水下点火的流体动力研究[J].航空学报,1992,13(4):B124.LU Chuanjing,CHEN Fang,FAN Hong,et al.The fluid dynamic research on the under-water ignition of missile[J].Acta Aeronautica et Astronautica Sinica,1992,13(4):B124.
[4]	黄建春,叶取源,朱世权.不同发射深度下导弹水下点火气水流体动力计算[J].应用力学学报,1994,11(3):19-24.HUANG Jianchun,YE Quyuan,ZHU Shiquan.Gas-water dynamic calculation for the underwater ignition of a missile at different depths[J].Chinese Journal of Applied Mechanics,1944,11(3);19-24.
[5]	王诚,叶取源,何友声.导弹水下发射燃气泡计算[J].应用力学学报,1997,14(3):1-7.WANG Cheng,YE Quyuan,HE Yousheng.Calculation of an exhausted gas cavity behind an under water launched missile[J].Chinese Journal of Applied Mechanics,1997,14(3):1-7.
[6]	单雪雄,杨荣国,叶取源.具有推力矢量控制系统的流体导弹流体动力[J].上海交通大学学报,2001,35(4):625-629.SHAN Xuexiong,YANG Rongguo,YE Quyuan.Fluidforces on a missile with control system of vectorial thrust[J].Journal of Shanghai Jiaotong University,2001,35(4):625-629.
[7]	张有为,王晓宏,杨举贤.利用球形气泡模型研究导弹水下点火瞬间的推力状况[J].水动力学研究与进展,2005,20(5):636-640.ZHANG Youwei,WANG Xiaohong,YANG Juxian.Study on the working thrust for the missile launching under water using the spherical bubble model[J].Journal of Hydrodynamics,2005,20(5):636～640.
[8]	张有为,王晓宏.导弹水下点火推力峰值问题的数值研究[J].应用力学学报,2007,24(1):298-301.ZHANG Youwei,WANG Xiaohong.Numerical research on thrust peak for missile launching underwater[J].Chinese Journal of Applied Mechanics,2007,24(1):298-301.
[9]	张有为,王晓宏,杨举贤.嵌金属丝端燃药柱燃烧过程的数值研究[J].推进技术,2007,28(1):4-8.ZHANG Youwei,WANG Xiaohong,YANG Juxian.Numerical study for end-burning solid motor embedded with wire[J].Journal of Propulsion Technology,2007,28(1):4-8.
[10]	张有为,王晓宏.嵌金属丝端燃药柱固体发动机水下点火数值模拟研究[J].固体火箭技术,2007,30(1):30-33.ZHANG Youwei,WANG Xiaohong,Study on numerical simulation of underwater launch for end-burning grain solid motor with embedded wire[J].Journal of Solid Rocket Technology,2007,30(1):30-33.
[11]	倪火才.潜载飞航导弹发射技术的发展[J].舰载武器,1997,4:7-16.NI Huocai.Development of submarine launched missile technology[J].Shipborne Weapons,1997,4:7-16.
[12]	王晓宏,陈义良,李潜,等.导弹水下发射时喷管的气体流动[J].推进技术,2001,22(1):61-64.WANG Xiaohong,CHEN Yiliang,LI Qian,et al.Nozzle flows of the missle launching under water[J].Journal of Propulsion Technology,2001,22(1);51-64.
[13]	清华大学工程力学系.流体力学基础[M].北京:机械工业出版社,1982.
