一种基于模型的双转子不平衡故障诊断方法
A model-based diagnosis method of unbalance faults for dual-spool system
-
摘要: 建立了双转子系统内外转子同时具有不平衡故障时振动响应分析模型,给出了双转子不平衡故障的微差速测试方法,构造了不平衡故障的非线性优化识别模型.分析了双转子可测点不平衡响应对转速与不平衡量之间的灵敏度关系,讨论了双转子不平衡故障的可诊断性问题,并利用数值仿真和试验对该方法进行了检验.研究表明,当测试数据含有一定的噪声时,利用少量的测点和转子的转速信息,可较准确地识别转子不平衡量故障.Abstract: Amodel for analyzing unbalance faults in dual-spool system was discussed.The dual-spool model was built using substructure transfer matrix method.Linear superposition theory was used to calculate the response on the support points when the inner and outer rotors have the unbalance faults at the same time.The method of little rotating speed difference for measuring unbalance vibration response was presented.The nonlinear optimization model for identifying the dual-spool unbalance faults was constructed,and the sequence quadratic programming(SQP) was employed to solve them.The sensibility relationship between the unbalance response from the accessible points and dual rotors speeds,or between the unbalance response and unbalance quantity,were given.The possibility of diagnosis for dual rotors unbalance faults was also discussed.The proposed methods are demonstrated using the numerical simulations and experiments.The results show that the method can successfully identify the magnitude and phase of unbalance for dual-spool using the information of speed and a few points' response data with noise.
-
[1] Zeng S,Wang X X.Unbalance identification and field balancing of dual rotors system with slightly different rotaring speeds[J].Journal of Sound and Vibration,1999,220(2):343-351. [2] 贺世正,周保堂,严利华.微速差双转子整机动平衡仪的开发与研究[J].仪器仪表学报,1999,29(6):633-636.HE Shizhen,ZHOU Baotang,YAN Lihua.Development and study for whole machine balancing of double shaft rotating with small speed difference[J].Chinese Journal of Scientific Instrument,1999,20(6):633-636. [3] 欧阳丹彤,欧阳继红,刘大有.基于模型诊断的研究与新进展[J],吉林大学自然科学学报,2001(2);38-45.OUYANG Dantong,OUYANG Jihong,LIU Dayou.The research and new development on model-based diagnosis[J].Journal of Jilin University(Science Edition),2001(2):38-45. [4] Jain J R,Kundra T K.Model based online diagnosis of unbalance and transverse fatigue crack in rotor systems[J].Mechanics Research Communications,2004,31:557-568. [5] Loparo K A,Adams M L,Lin Wei,et al.Fault detection and diagnosis of rotating machinery[J].IEEE Transactions on Industrial Electronics,2000:1005-1014. [6] Isermann.Model-based fault detection and diagnosis:status and applications[C]//In Proceedings of the 16th IFAC Symposium on Automatic Control in Aerospace,St.Petersburg,Russia:[s.n.]:2004. [7] 晏励堂.航空燃气轮机振动和减振[M].北京:国防工业出版社,1991. [8] 《航空发动机设计手册》总编委会编.转子动力学及整机振动[M]//航空发动机设计手册:第19册.北京:航空工业出版社,2000. [9] 魏海涛,范晓明.机动飞行中双转子系统的振动响应分析[C]//中国航空学会第十届航空发动机结构强度与振动会议论文集.安徽,歙县:中国航空学会,2000:315-320. [10] 杨健,周保堂.微差速双转子系统振动信号分离法研究[J].中国机械工程,2002(8):710-713.YANG Jian,ZHOU Baotang.Research on the separating method of vibration signals for the dual-rotor system with little speed difference in the rotating machinery[J].China Mechanical Engineering,2002(8):710-713. [11] 袁亚湘,孙文瑜.最优化理论与方法[M].北京:科学出版社,2001. -
