高超进气道临界起动特征
Critical starting characteristics of hypersonic inlets
-
摘要: 通过对一种吸气式高超飞行器模型的Ma=7风洞吹风试验结果的分析,获得了高超进气道不起动、临界起动和起动状态的流动特征,包括流动图谱、压力分布和气动力分布;并将进气道内收缩比值与等熵理论最大起动收缩比限、自起动最大起动收缩比限和经验最大起动收缩比限做了对比分析,分析结果有助于高超进气道的设计和起动性能的评估.Abstract: An airbreathing hypersonic vehicle model was tested in the Ma=7 wind tunnel.The experimental investigations yielded schlieren pictures of the inlet flow,static surface pressure measurements along inlet/internal flowpath and aerodynamic force distributions.The flow field characteristics were achieved,such as: unstarting hypersonic inlet,critical starting and starting condition.The ability of isentropic limit,Kantrowitz limit and Van Wie limit to predict the starting contraction ratio was assessed,showing that the isentropic limit and Van Wie limit could not estimate the allowable starting and maximum contraction ratio.The Kantrowitz limit is slightly conservative.The above results are helpful to the design of the hypersonic inlet and the assessment of starting performance.
-
[1] Kantrowitz A,Donaldson C.Preliminary investigation of supersonic diffuser[R].NACA WRL-713,1945. [2] Van Wie D M,Kwok F T,Walsh R F.Starting characteristics of supersonic inlets[R].AIAA 96-2914. [3] 孙波,张堃元.Busemann进气道起动问题初步研究[J].推进技术,2006,27(2):128-131.SUN Bo,ZHANG Kunyuan.Preliminary investigation on Busemann inlet starting characteristics[J].Journal of Propulsion Technology,2006,27(2):128-131. [4] Sannu Molder.Flow starting in high compression hypersonic air inlets by mass spillage[R].AIAA-2004-4130. [5] 王成鹏,程克明,王江峰,等.高超声速风洞流场校测和标模测力[C]//CARS-200600062,中国第一届近代空气动力学与气动热力学会议论文集.绵阳:中国空气动力学会,2006,8:356-361.WANG Chengpeng,CHENG Keming,WANG Jiangfeng,et al.Flow field calibrations and force tests of an AGARD model in a hypersonic wind tunnel of NUAA[C]//CARS-200600062,Proceedings of China 1st Modern Aerodynamics & Aerothermodynamics Conference.Mianyang:China Aerodynamics Research Society,2006:356-361. [6] 王成鹏,张红英,孙妹,等.高超飞行器进气道/内流道流动特性试验[J].航空动力学报,2007,22(10):1704-1709.WANG Chengpeng,ZHANG Hongying,SUN Shu,et al.Experimental study of integrated inlet/internal flow-path for an airbreathing hypersonic vehicle[J].Journal of Aerospace Power,2007,22(10):1704-1709.
