基于全局气动优化方法的跨声速叶栅气动优化
Aerodynamic optimization of transonic cascade using global aerodynamic optimization method
-
摘要: 提出了适用于叶栅三维气动设计优化的全局自动气动优化方法.对NASA Rotor 37转子叶栅进行了气动优化设计.利用该叶栅的试验数据校核了计算流体(CFD)程序的可靠性.以等熵效率最高为目标函数,在满足流量约束和总压比约束的条件下,完成了跨声速叶栅的气动优化设计.优化叶栅的等熵效率提高了1.66%,具有优秀的气动性能和变工况性能.优化结果表明,通过优化三维跨声速叶栅的型线和径向基迭方式,可以有效的减小跨声速叶栅的激波损失.Abstract: A global aerodynamic optimization method was proposed for three-dimensional cascade design.The method was applied to the NASA Rotor 37,which was a test transonic compressor cascade representing complex three-dimensional viscous flow structures.The capability of the computational fluid dynamics(CFD) code was validated by comparing the computed results with experimental data available in the open literature.The transonic cascade was optimized for the maximization of the isentropic efficiency under given flow conditions,using constraints on the mass flow rate and the total pressure ratio.The isentropic efficiency of the optimized design was 1.66% higher than that of the reference design,showing a better aerodynamic performance and better off-design performance.It shows that the shock losses of the transonic cascade could be reduced by optimizing the profiles of the transonic cascade and its radial stacking mode.
-
[1] Michalewica Z.Genetic algorithms+data structures=evolution programs[M].Berline:Springer-Verlag,1996. [2] SONG Liming,FENG Zhenping,LI Jun.Shape optimization of turbine stage using adaptive range differential evolution and three-dimensional Navier-Stokes solver[R].Nevada:ASME Turbo Expo 2005,ASME Paper 2005-GT-68280,2005:1033-1040. [3] Benini E.Three-dimensional multi-objective design optimization of a transonic compressor rotor[J].Journal of Propulsion and Power,2004,20(3):559-565. [4] Toyotaka S.A study of advanced high-loaded transonic turbine airfoils[J].ASME Journal of Turbomachinery,2006,(128):650-657. [5] Storn R.Minimizing the real functions of the ICEC'96 contest by differential evolution[R].Nagoya:IEEE Conference on Evolutionary Computation,1996:842-844. [6] Hrstka O.A competitive comparison of different types of evolutionary algorithms[J].Computers & Structures,2003,81:1979-1990. [7] Korakianitis T.Surface-curvature-distribution effects on turbine-cascade performance[J].ASME Journal of Turbomachinery,1993,(115):334-340. [8] Reid L,Moore R D.Design and overall performance of four highly loaded,high-speed inlet stages for an advanced high-pressure ratio core compressor[R].NASA TP 1337,1978. [9] Moore R D,Reid L.Performance of single axial flow transonic compressor with rotor and stator aspect ratio of 1.19 and 1.26,respectively,and with design pressure ratio of 2.05[R].NASA TP 1659,1980. -
