改进的流线曲率通流计算方法及在双涵道压缩系统设计中的应用
Improved streamline curvature throughflow method and its application in a bypass compression system design
-
摘要: 基于轴对称的S2流面理论,发展了一套流线曲率通流计算方法.为了提高计算的收敛性、稳定性和计算精度,对求解过程中的流线曲率计算、松弛因子的选取等方面进行了改进;提出了一种简单易行的叶片力的处理方法,使得该方法可以计算叶片排以内的区域;为了计算风扇和轴流、离心以及组合压气机构成的双涵道压缩系统,发展了一种计算速度快、稳定性好的双涵道计算方法.最后将改进的通流计算方法用于一双涵道压缩系统的反设计,验证了其可行性.Abstract: Based on axisymmetric S2 stream surface theory,a streamline curvature throughflow method is presented in this paper.Improvements on streamline curvature calculation and relaxation factor determination were made,which enhanced the convergence,stability and precision of this method.Asimple blade force handling method was also proposed for computing flow field in the blade passage.At the same time,a bypass compression system computational method was integrated,which was stable and fast,and which enabled this method to solve arbitrary regions in bypass compression systems composed of fans and any type of high pressure compressors(axial-flow,centrifugal and combined type etc.).Finally this method was applied to an inverse design of a fan/high pressure compressor system,which demonstrated its validity.
-
[1] Wu C H.A general through flow theory of three-dimensional flow in subsonic and supersonic turbomachines of axial,radial and mixed flow types[R].NACA-TN-2604,1952. [2] Marsh H.A digital computer program for the throughflow fluid mechanics in an arbitrary turbomachines,using a matrix method[R].ARC R & M.No.3509,1968. [3] Novak R A,Hearsey R M.A nearly three-dimensional intrablade computing system for turbomachinery[J].Journal of Fluids Engineering,1977,99:154-166. [4] Jennions I K,Stow P.A quasi-three-dimensional turbomachinery blade design system:Part Ⅰ-Through flow analysis[J].Journal of Engineering for Gas Turbines and Power,1985,107:301-307. [5] Novak R A.Streamline curvature computing procedures for fluid-flow problems[J].Journal of Engineering for Power,1967,89:478-490. [6] Denton J D.Throughflow calculation for transonic axial flow turbines[J].Journal of Engineering for Power,1978,100:212-218. [7] Wennerstrom A J.Design of highly loaded axial-flow fans and compressors[M].Concepts ETI Inc,USA,2000. [8] Cumpsty N A.Compressor aerodynamics[M].England:Longman Scientific & Technical,1989. [9] Frost D H.A streamline curvature through-flow com-puter program for analyzing the flow through axial-flow turbomachines[R].ARC R & M No.3687,1972. [10] Hirsch C H,Warzee G.A finite element method for throughflow calculation in turbomachines[J].Journal of Fluids Engineering,1976,101:141-148. [11] Damle S V.Throughflow method for turbomachines using Euler solvers[R].AIAA 96-0010.1996. [12] Horlock J H.On entropy production in adiabatic flow in turbomachines[J].Journal of Basic Engineering,1971,93:587-593. [13] Wilkinson D H.Stability,convergence and accuracy of two-dimensional streamline curvature methods using quasiorthogonals[J].ImechE,1969-70,184.
