磁悬浮阻尼器对磁悬浮转子系统动态特性影响

谢振宇; 李克雷; 赵钦泉; 黄佩珍

磁悬浮阻尼器对磁悬浮转子系统动态特性影响

1.
南京航空航天大学机电学院, 南京 210016
2.
南京航空航天大学航空宇航学院, 南京 210016

基金项目: 国家自然科学基金(50675105);江苏省自然科学基金(BK2003420)

计量
- 文章访问数: 1526
- HTML浏览量: 115
- PDF量: 420
- 被引次数: 0
出版历程
- 收稿日期: 2007-08-06
- 修回日期: 2008-03-31
- 刊出日期: 2008-06-28

Influence of magnetic damper on dynamic characteristics of magnetic bearing system

1.
College of Mechanical and Electrical Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2.
College of Aerospace Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 为改善磁悬浮轴承细长转子系统的动态性能,在原有支承基础上增加磁悬浮阻尼器.分析了磁悬浮轴承与磁悬浮阻尼器组合柔性转子系统的动态性能,并与不含磁悬浮阻尼器系统的动态性能进行了比较.由于增加了合适位置及合适控制参数的磁悬浮阻尼器,提高了系统在第1,2阶弯曲模态振动时的阻尼,使系统顺利越过二阶弯曲临界转速在16000r/min稳定运行.
- 航空、航天推进系统 /
- 磁悬浮轴承 /
- 动态特性 /
- 固有频率 /
- 振型 /
- 阻尼
Abstract: Dynamic characteristics of the system supported by two radial magnetic bearings,one axial magnetic bearing and one magnetic damper are studied in this paper.Compared with the system without magnetic damper,supporting damping of the system increases obviously and the vibration of the system can be reduced effectively,especially when it operates on the first two bending critical speeds.This helps the system to get across the first two bending critical speeds safely and operate on16 000 rotations per minute.
- aerospace propulsion system /
- active magnetic bearing /
- dynamic characteristics /
- critical speed /
- mode shape /
- damping

HTML

参考文献(7)

[1]	Ueyama H.Helium cold compressor with active magnetic bearings[C]//Proc.of the 7th Int.Symp.on Magnetic Bearings.Zurich,Switzerland:[s.n.],August 2000:1-6.
[2]	谢振宇,徐龙样,李迎,等.控制参数对磁悬浮轴承转子系统动态特性的影响[J].航空动力学报,2004,19(2):174-178.XIE Zhenyu,XU Longxiang,LI Ying,et al.Influence of control parameters on dynamic characteristics of active magnetic bearing system[J].Journal of Aerospace Power,2004,19(2):174-178.
[3]	谢振字,徐龙祥,李迎,等.磁悬浮轴承转子系统动态特性的实验研究[J].航空动力学报,2004,19(1):30-37.XIE Zhenyu,XU Longxiang,LI Ying,et al.Analysis of radial dynamic characteristics of magnetic bearing system by excitation Test[J].Journal of Aerospace Power,2004,19(1):30-37.
[4]	Zhang H,Lin Z I,Allaire PE.Control of magnetic bearing levitated flexible rotor system:A convex optimization approach[C]//Proc.of the 9th Int.Symp.on Magnetic Bearings.Lexington,Kentucky,USA:August,2004.
[5]	GU Huidong,ZHAO Lei,ZHAO Hongbin.A LQG controller design for an AMB-flexible rotor system[C]//Proc.Of the 9th Int.Symp.On Magnetic Bearings.Lexington,Kentucky,USA:August,2004.
[6]	Okada Y,Shimizu K,Ueno S.Vibration control of flexible rotor by inclination control magnetic bearings with axial self-bearing motor[J].IEEE/ASME Transactions on Mechatronics,2001,6(4):521-524.
[7]	Schonhoff U,Luo J H,Allaire P.Implementation results of μ-synthesis control for an energy storage flywheel test rig[C]//Proc.of the 7th Int.Symp.on Magnetic Bearings.ETH,Zurich:August,2000.
