大涡模拟模型环形燃烧室污染特性
Large eddy simulation of pollution formation in model annular combustor
-
摘要: 在任意曲线坐标系下,采用大涡模拟模型环形燃烧室两相燃烧流场中污染物的生成.用亚网格涡破碎(EBU)燃烧模型估算化学反应速率;分别用NO亚网格动力学模型与CO亚网格模型来模拟NO和CO的生成;采用随机离散模型模拟气液两相湍流流动,两相之间耦合采用PSIC算法.计算结果与瞬态速度场、出口温度和污染物质量分数分布的实验数据比较吻合,表明大涡模拟方法和亚网格模型可以用来预估实际燃烧室两相喷雾燃烧流场和污染物生成过程.
-
关键词:
- 大涡模拟 /
- 模型环形燃烧室 /
- 亚网格污染物生成模型 /
- 随机离散模型
Abstract: In three-dimensional arbitrary curvilinear coordinates,large-eddy simulation(LES) approach was employed to simulate pollution formations in the model annular combustor.The k-equation subgrid scale model was used to simulate the subgrid eddy viscosity,the eddy-break-up(EBU) combustion subgrid scale model was applied to prediction of the chemical reaction rate,the NOsubgrid scale pollutant formation model was employed to the evaluation of the rate of NOformation,and a two-step turbulent combustion subgrid scale model was applied for calculating COconcentration.Astochastic separated flow formulation was applied to prediction of instantaneous gas-liquid two-phase turbulent combustion flows.The numerical simulation results were in reasonable agreement with the experimental instantaneous velocity profiles in the primary zone,temperature and pollution concentration profiles at the outlet.It shows that the LESmethod and subgrid scale pollution formation models in this study can be used to investigate turbulent two-phase combustion and pollution formation processes in combustors. -
[1] Eggenspieler G,Menon S.Large-eddy simulation of pollutant emission in a DOE-HAT Combustor[R].AIAA 2003.309,2003. [2] Cannon S M,Smith C E.LES predictions of combustor emissions an aero gas turbine engine[R].AIAA 2003-4521,2003. [3] Grinstein F F,Fureby C.LES studies of the flow in a swirl gas combustor[J].Proceedings of the Combustion Institute,2005,30:1791-1798. [4] 颜应文,赵坚行.加力燃烧室污染特性的大涡模拟[J].燃烧科学与技术,2005,11(1):68-72.YAN Yingwen,ZHAO Jianxing.Large-eddy simulation of pollutant performance in an afterburner[J].Journal of Combus-tion Science and Technology,2005,11(1):68-72.(in Chinese) [5] Menon S,Pannala S.Subgrid simulations of reacting two-phase shear layers[R].AIAA98-3318,1998. [6] Avancha R V R,Pletcher R H.Largr eddy simulation of the turbulent flow past a backward step[R].AIAA 2000-0542.2000. [7] 颜应文.赵坚行.模型燃烧室紊流燃烧的大涡模拟[J].航窄动力学报,2005.20(1):86-91.YAN Yingwen,ZHAO Jianxing.Large-eddy simulation of turbulent combustion in a model combustor[J].Journal of Aerospace Power,2005,20(1):86-91.(in Chinese) [8] 颜应文,赵坚行,张靖周,等.三维贴体坐标系下燃烧室热态流场的大涡模拟[J].推进技术,2005,26(3):219-222.YAN Yingwen,ZHAO Jianxing,ZHANG Jingzhou,et al.Large-eddy simulation of turbulent reacting flows in the com-bustor by three-dimensional body-fitted grid[J].Journal of Propulsion Technology,2005,26(3):219-222.(in Chinese) [9] 颜应文,赵坚行,张靖周,等.燃烧室两相流场亚网格燃烧模型的研究[J].力学学报,2006,38(6):784-790.YAN Yingwen,ZHAO Jianxing,ZHANG Jingzhou,et al.Sub-grid scale combustion models for two-phase combustion flow in an annular combustor[J].Chinese Journal of Theoretical and Applied Mechanics,2006,38(6):782-790.(in Chinese) [10] 颜应文,赵坚行,张靖周,等.环形燃烧室两相喷雾燃烧的大涡模拟[J].航空动力学报,2006,21(5):824-830.YAN Yingwen,ZHAO Jianxing,ZHANG Jingzhou,et al.Large-eddy simulation of turbulent spray combustion in an annu-lar combustor[J].Journal of Aerospace Power,2006,21(5):824-830.(in Chinese)
