涡轮叶片尾缘通道中纵向肋对换热特性的影响

基金项目: 国家自然科学基金青年科学基金(50606002)

Effect of different clapboards structure in turbine blade trailing edge complex passages on heat transfer characteristics

National Key Laboratory on Aero-engines, School of Jet Propulsion, Beijing Universty of Aeronautics and Astronautics, Beijing 100083, China

摘要: 采用冷凝水蒸汽的实验方法,测量三种不同类型纵向肋对叶片尾缘通道的换热影响.系统的研究了孔径为2.6mm的带孔平肋,波峰孔径为3mm、波谷孔径为2.2mm的波浪肋,和不带孔平肋之间的换热和流阻比较,实验结果表明:当Re<20000时,波浪肋的换热优于带孔平肋,当Re>50000时,波浪肋换热不及不带孔平肋.且波浪肋流阻远低于不带孔平肋和带孔平肋.
- 换热特性 /
- 涡轮叶片尾缘通道 /
- 隔板 /
- 流阻
Abstract: The effect of three different dividers on the heat transfer of turbine blade trailing passage was investigated experimentally.The condensation vapor method was used in the experiment.Heat transfer and hydrodynamic drag were compared among the straight divider with hole of 2.6 mm in diameter,waved divider with hole of 3 mm in diameter on wave crest and hole of 2.2 mm in diameter on trough,and straight divider without hole.The waved divider gave better heat transfer than the straight divider with hole when the Re<20000.For the case of Re>50000,the waved divider showed worse heat transfer than the straight divider without hole.The drag of the waved divider was far less than that of the straight divider with or without hole.
- heat transfer characteristics /
- turbine blade trailing edge /
- dividers /
- flowing resistance

[1]	Metzger D E,Berry R A.Developing heat transfer in rectangular ducts with staggered pin fins[J].Trans ASME J Heat Transfer,1982,104:700-706.
[2]	Hwang J J,Lui C C.Detailed heat transfer characteristic comparison inrectangular and 90-deg turned trapezoidal ducts with pin-fin arrays[J].International Journal of Heat and Mass Transfer,1999,42:4005-4016.
[3]	李莉,丁水汀,陶智,等.涡沦叶片尾缘复合通道的换热[J].北京航空航天人学学报,2005,31(2):302-205.LI Li,DING Shuiting,TAO Zhi,et al.Heart transfer in complex passages of turbine blade trailiing edge[J].Journal of Beijing University of Aeronautics and Astronautics,2005,31(2):202-205.(in Chinese)
[4]	丁水汀,刘丽艳,李莉,等.涡沦叶片尾缘复合通道中隔板结构对换热特性的影响[J].航空动力学报,2006,21(3):523-527.DING Shuiting,LIU Liyan,LI Li,et al.The effect of different structure clapboards in complex passages on heat transfer characteristics of turbine blade trailing edge[J].Journal of Aerospace Power,2006,21(3):523-527.(in Chinese)
[5]	邓宏武,潘文艳,陶智,等.开槽交错肋通道换热和流阻特性[J].北京航空航天大学学报,2007,33(10):1158-1161.DENG Hongwu.PAN Wenyan,TAO Zhi,et al.Heat transfer and flow resistance in a notched crossed-rib channel[J].Journal of Beijing University of AeronauticsAndastronautic,2007,33(10):1158-1161.(in Chinese)
