混合管出口掺混距离对气流温度的影响

唐正府; 张靖周; 单勇

混合管出口掺混距离对气流温度的影响

南京航空航天大学能源与动力学院, 南京 210016

计量
- 文章访问数: 1476
- HTML浏览量: 1
- PDF量: 414
- 被引次数: 0
出版历程
- 收稿日期: 2007-06-28
- 修回日期: 2008-04-28
- 刊出日期: 2008-07-28

Effect of relative space between mixing duct exits on the flow temperature

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 就弯曲混合管出口与模型出口之间相对距离的改变,对一体化红外抑制器模型出口混合气流温度的影响进行了数值模拟和分析.并通过实验,对出口间距变化时模型壁面的红外辐射场进行了测量.结果表明,延长混合管出口与模型出口之间相对距离,可以增加混合管热排气与冷却气流的掺混距离,使模型出口混合气流温度峰值下降约42%;但同时会使模型壁面在3～5μm波段和8～14μm波段的红外辐射强度有所增加.
- 红外辐射 /
- 弯曲混合管 /
- 一体化红外抑制器 /
- 出口间距
Abstract: Anumerical simulation and analysis of infrared radiation field of the integrative infrared suppressor model was performed to investigate the effects of space between the model exit and curved mixing duct exit,meanwhile the temperature field of the model exit was also obtained by numerical simulation.The results show that the mixing flow temperature of the model exit will decrease 42% by extending the distances between exits,because mixing hot exhaust with rotor downwash is enhanced greatly.At the same time,the infrared radiant intensity is increased slightly between3～5μm and 8～14μm.
- infrared radiation /
- curved mixing duct /
- integrative infrared suppressor /
- space between exits

HTML

参考文献(8)

[1]	Armand F,Amelio Y.Infrared suppression for a gas turbine engine:US.Patent 5699955[P].1997.
[2]	Mark H,Walter M.Exhaust nozzle for suppressing infrared radiation:US,Patent 5992140[P].1999.
[3]	张靖周,李立国,高潮.直升机排气系统红外抑制器的模型实验研究[J].红外与毫米波学报,2005,24(2):125-129.ZHANG Jingzhou,LI Liguo,GAO Chao.Model experiments of infrared suppressor for helicopter exhaust system[J].Journal of Infrared and Millimeter Waves,2005,24(2):125-129.(in Chinese)
[4]	Kanclebo S W.Boeing silorsky findings underscore RAH-66 stealth[R].AW and ST,1993,22-23.
[5]	王先炜,黄勇,路玉霞.旋翼下洗气流对红外抑制器性能的影响研究[J].航空动力学报,2003,18(6):773-776.WANG Xianwei,HUANG Yong,LU Yuxia.Influences of the downwash flow from a helicopter rotor on the performances of an infrared suppressor[J].Journal of Aerospace Power,2003,18(6):773-776.(in Chinese)
[6]	唐正府,张靖周.波瓣喷管-狭长出口弯曲混合管引射混合特性分析[J],航空动力学报,2005,20(6);978-982.TANG Zhengfu,ZHANG Jingzhou.Investigation on ejecting and mixing characteristics of lobed nozzle with curved mixing duct and slot exit[J].Journal of Aerospace Power,2005,20(6):978-982.(in Chinese)
[7]	唐正府.张靖周.排气系统与机身一体化红外抑制器实验分析[J].航空动力学报,2007,22(2):233-237.TANG Zhengfu,ZHANG Jingzhou.Experimental research on infrared suppressor integrating the exhaust system with the tail part of a helicopter[J].Journal of Aerospace Power,2007,22(2):233-237.(in Chinese)
[8]	单勇,张靖周.渡瓣喷管引射-混合器的数值研究与验证[J].推进技术,2004,25(4):320-324.SHAN Yong,ZHANG Jingzhou.Numerical computation and examination of a lobed mixer-ejector[J].Journal of Propulsion Technology,2004,25(4):320-324.(in Chinese)
